Ejercicios Docker
Todos estos ejercicios estarán sacados del curso de Docker de José Domingo.
Introducción
Instalación de docker
Instalo la versión de comunidad de Debian:
Hago que mi usuario sin privilegios pueda usar el cliente de docker (para que este cambio surta efecto tendremos que cerrar sesión y volver a logearnos con nuestro usuario):
Pruebo que Docker se instaló:
El “Hola Mundo” de docker
Creamos nuestro primer contenedor desde la imagen hello-world:
atlas@olympus:~$ docker run hello-world
Unable to find image 'hello-world:latest' locally
latest: Pulling from library/hello-world
2db29710123e: Pull complete
Digest: sha256:80f31da1ac7b312ba29d65080fddf797dd76acfb870e677f390d5acba9741b17
Status: Downloaded newer image for hello-world:latest
Hello from Docker!
This message shows that your installation appears to be working correctly.
To generate this message, Docker took the following steps:
1. The Docker client contacted the Docker daemon.
2. The Docker daemon pulled the "hello-world" image from the Docker Hub.
(amd64)
3. The Docker daemon created a new container from that image which runs the
executable that produces the output you are currently reading.
4. The Docker daemon streamed that output to the Docker client, which sent it
to your terminal.
To try something more ambitious, you can run an Ubuntu container with:
$ docker run -it ubuntu bash
Share images, automate workflows, and more with a free Docker ID:
https://hub.docker.com/
For more examples and ideas, visit:
https://docs.docker.com/get-started/
Para listar los contenedores ejecutándose:
Para listar todos los contenedores, no ejecutándose o ejecutándose:
atlas@olympus:~$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
0653f26a58dc hello-world "/hello" 6 minutes ago Exited (0) 6 minutes ago blissful_ardinghelli
Para eliminar contenedores por id:
Para eliminar contenedores por nombre:
Ejecución simple de contenedores
Ejecutamos un echo desde una imagen Ubuntu:
atlas@olympus:~$ docker run ubuntu echo 'Hello world'
Unable to find image 'ubuntu:latest' locally
latest: Pulling from library/ubuntu
405f018f9d1d: Pull complete
Digest: sha256:b6b83d3c331794420340093eb706a6f152d9c1fa51b262d9bf34594887c2c7ac
Status: Downloaded newer image for ubuntu:latest
Hello world
Comprobamos que el contenedor se ha parado:
atlas@olympus:~$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
45c6f4b0dbcc ubuntu "echo 'Hello world'" 2 minutes ago Exited (0) 2 minutes ago competent_davinci
Para listar las imágenes que ya tenemos descargadas:
atlas@olympus:~$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
ubuntu latest 27941809078c 2 days ago 77.8MB
hello-world latest feb5d9fea6a5 8 months ago 13.3kB
Ejecutando un contenedor interactivo
Para volver a conectarnos al contenedor después de habernos salido:
atlas@olympus:~$ docker start contenedor1
contenedor1
atlas@olympus:~$ docker attach contenedor1
root@38c803b78559:/#
Para ejecutar comandos sobre un contenedor en ejecución:
atlas@olympus:~$ docker start contenedor1
contenedor1
atlas@olympus:~$ docker exec contenedor1 ls -la
total 56
drwxr-xr-x 1 root root 4096 Jun 9 19:11 .
drwxr-xr-x 1 root root 4096 Jun 9 19:11 ..
-rwxr-xr-x 1 root root 0 Jun 9 19:11 .dockerenv
lrwxrwxrwx 1 root root 7 May 31 15:42 bin -> usr/bin
drwxr-xr-x 2 root root 4096 Apr 18 10:28 boot
drwxr-xr-x 5 root root 360 Jun 9 19:24 dev
drwxr-xr-x 1 root root 4096 Jun 9 19:11 etc
drwxr-xr-x 2 root root 4096 Apr 18 10:28 home
lrwxrwxrwx 1 root root 7 May 31 15:42 lib -> usr/lib
lrwxrwxrwx 1 root root 9 May 31 15:42 lib32 -> usr/lib32
lrwxrwxrwx 1 root root 9 May 31 15:42 lib64 -> usr/lib64
lrwxrwxrwx 1 root root 10 May 31 15:42 libx32 -> usr/libx32
drwxr-xr-x 2 root root 4096 May 31 15:42 media
drwxr-xr-x 2 root root 4096 May 31 15:42 mnt
drwxr-xr-x 2 root root 4096 May 31 15:42 opt
dr-xr-xr-x 443 root root 0 Jun 9 19:24 proc
drwx------ 1 root root 4096 Jun 9 19:13 root
drwxr-xr-x 5 root root 4096 May 31 15:45 run
lrwxrwxrwx 1 root root 8 May 31 15:42 sbin -> usr/sbin
drwxr-xr-x 2 root root 4096 May 31 15:42 srv
dr-xr-xr-x 13 root root 0 Jun 9 19:24 sys
drwxrwxrwt 2 root root 4096 May 31 15:45 tmp
drwxr-xr-x 14 root root 4096 May 31 15:42 usr
drwxr-xr-x 11 root root 4096 May 31 15:45 var
Para reiniciar un contenedor:
Para mostrar información sobre un contenedor:
atlas@olympus:~$ docker inspect contenedor1
[
{
"Id": "38c803b78559b214a1e74377faf006cb1758e9bee4619c782783fd685e84b192",
"Created": "2022-06-09T19:11:27.622457379Z",
"Path": "bash",
"Args": [],
"State": {
"Status": "running",
"Running": true,
"Paused": false,
"Restarting": false,
"OOMKilled": false,
"Dead": false,
"Pid": 22633,
"ExitCode": 0,
"Error": "",
"StartedAt": "2022-06-09T19:27:04.276188002Z",
"FinishedAt": "2022-06-09T19:27:03.593607062Z"
},
"Image": "sha256:27941809078cc9b2802deb2b0bb6feed6c236cde01e487f200e24653533701ee",
"ResolvConfPath": "/var/lib/docker/containers/38c803b78559b214a1e74377faf006cb1758e9bee4619c782783fd685e84b192/resolv.conf",
"HostnamePath": "/var/lib/docker/containers/38c803b78559b214a1e74377faf006cb1758e9bee4619c782783fd685e84b192/hostname",
"HostsPath": "/var/lib/docker/containers/38c803b78559b214a1e74377faf006cb1758e9bee4619c782783fd685e84b192/hosts",
"LogPath": "/var/lib/docker/containers/38c803b78559b214a1e74377faf006cb1758e9bee4619c782783fd685e84b192/38c803b78559b214a1e74377faf006cb1758e9bee4619c782783fd685e84b192-json.log",
"Name": "/contenedor1",
"RestartCount": 0,
"Driver": "overlay2",
"Platform": "linux",
"MountLabel": "",
"ProcessLabel": "",
"AppArmorProfile": "docker-default",
"ExecIDs": null,
"HostConfig": {
"Binds": null,
"ContainerIDFile": "",
"LogConfig": {
"Type": "json-file",
"Config": {}
},
"NetworkMode": "default",
"PortBindings": {},
"RestartPolicy": {
"Name": "no",
"MaximumRetryCount": 0
},
"AutoRemove": false,
"VolumeDriver": "",
"VolumesFrom": null,
"CapAdd": null,
"CapDrop": null,
"CgroupnsMode": "private",
"Dns": [],
"DnsOptions": [],
"DnsSearch": [],
"ExtraHosts": null,
"GroupAdd": null,
"IpcMode": "private",
"Cgroup": "",
"Links": null,
"OomScoreAdj": 0,
"PidMode": "",
"Privileged": false,
"PublishAllPorts": false,
"ReadonlyRootfs": false,
"SecurityOpt": null,
"UTSMode": "",
"UsernsMode": "",
"ShmSize": 67108864,
"Runtime": "runc",
"ConsoleSize": [
0,
0
],
"Isolation": "",
"CpuShares": 0,
"Memory": 0,
"NanoCpus": 0,
"CgroupParent": "",
"BlkioWeight": 0,
"BlkioWeightDevice": [],
"BlkioDeviceReadBps": null,
"BlkioDeviceWriteBps": null,
"BlkioDeviceReadIOps": null,
"BlkioDeviceWriteIOps": null,
"CpuPeriod": 0,
"CpuQuota": 0,
"CpuRealtimePeriod": 0,
"CpuRealtimeRuntime": 0,
"CpusetCpus": "",
"CpusetMems": "",
"Devices": [],
"DeviceCgroupRules": null,
"DeviceRequests": null,
"KernelMemory": 0,
"KernelMemoryTCP": 0,
"MemoryReservation": 0,
"MemorySwap": 0,
"MemorySwappiness": null,
"OomKillDisable": null,
"PidsLimit": null,
"Ulimits": null,
"CpuCount": 0,
"CpuPercent": 0,
"IOMaximumIOps": 0,
"IOMaximumBandwidth": 0,
"MaskedPaths": [
"/proc/asound",
"/proc/acpi",
"/proc/kcore",
"/proc/keys",
"/proc/latency_stats",
"/proc/timer_list",
"/proc/timer_stats",
"/proc/sched_debug",
"/proc/scsi",
"/sys/firmware"
],
"ReadonlyPaths": [
"/proc/bus",
"/proc/fs",
"/proc/irq",
"/proc/sys",
"/proc/sysrq-trigger"
]
},
"GraphDriver": {
"Data": {
"LowerDir": "/var/lib/docker/overlay2/9fad5d5cd99a61193d036952be9856f4306065f1f2b98eec3069c1c4c25c2242-init/diff:/var/lib/docker/overlay2/4c732dfff53d5fd606c32c363b213c57a8926899ca739453ebaa448ac601efed/diff",
"MergedDir": "/var/lib/docker/overlay2/9fad5d5cd99a61193d036952be9856f4306065f1f2b98eec3069c1c4c25c2242/merged",
"UpperDir": "/var/lib/docker/overlay2/9fad5d5cd99a61193d036952be9856f4306065f1f2b98eec3069c1c4c25c2242/diff",
"WorkDir": "/var/lib/docker/overlay2/9fad5d5cd99a61193d036952be9856f4306065f1f2b98eec3069c1c4c25c2242/work"
},
"Name": "overlay2"
},
"Mounts": [],
"Config": {
"Hostname": "38c803b78559",
"Domainname": "",
"User": "",
"AttachStdin": true,
"AttachStdout": true,
"AttachStderr": true,
"Tty": true,
"OpenStdin": true,
"StdinOnce": true,
"Env": [
"PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
],
"Cmd": [
"bash"
],
"Image": "ubuntu",
"Volumes": null,
"WorkingDir": "",
"Entrypoint": null,
"OnBuild": null,
"Labels": {}
},
"NetworkSettings": {
"Bridge": "",
"SandboxID": "ddca79ac78e8d67018fe07a11ca7c316e2a74e58e11aca41ef07cb44a960aacd",
"HairpinMode": false,
"LinkLocalIPv6Address": "",
"LinkLocalIPv6PrefixLen": 0,
"Ports": {},
"SandboxKey": "/var/run/docker/netns/ddca79ac78e8",
"SecondaryIPAddresses": null,
"SecondaryIPv6Addresses": null,
"EndpointID": "868b39bc434bcdc04637157879fcf3b5bee0a09c5f44e6a438ddbb7f05e2802d",
"Gateway": "172.17.0.1",
"GlobalIPv6Address": "",
"GlobalIPv6PrefixLen": 0,
"IPAddress": "172.17.0.2",
"IPPrefixLen": 16,
"IPv6Gateway": "",
"MacAddress": "02:42:ac:11:00:02",
"Networks": {
"bridge": {
"IPAMConfig": null,
"Links": null,
"Aliases": null,
"NetworkID": "d9afc200992598b8c58b8b9387d37f9d4575203de95b19a0d9c0b643073c8759",
"EndpointID": "868b39bc434bcdc04637157879fcf3b5bee0a09c5f44e6a438ddbb7f05e2802d",
"Gateway": "172.17.0.1",
"IPAddress": "172.17.0.2",
"IPPrefixLen": 16,
"IPv6Gateway": "",
"GlobalIPv6Address": "",
"GlobalIPv6PrefixLen": 0,
"MacAddress": "02:42:ac:11:00:02",
"DriverOpts": null
}
}
}
}
]
Todas las imágenes tienen definidas un proceso que se ejecuta. La imagen ubuntu tiene definida por defecto el proceso bash, por lo que podríamos haber ejecutado:
Creando un contenedor demonio
Para ejecutar un comando en un contenedor en segundo plano:
atlas@olympus:~$ docker run -d --name contenedor2 ubuntu bash -c "while true; do echo hello world; sleep 1; done"
29039571153e129b1f4d901a2e9a270385fee1905c877dda3c13de53b7ad9eb4
Comprobar que el contenedor se sigue ejecutando:
atlas@olympus:~$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
29039571153e ubuntu "bash -c 'while true…" 14 minutes ago Up 14 minutes contenedor2
Comprobar lo que está haciendo el contenedor (bucle infinito de echo):
Paramos y borramos el contenedor:
atlas@olympus:~$ docker stop contenedor2
contenedor2
atlas@olympus:~$ docker rm contenedor2
contenedor2
Un contenedor en ejecución no puede ser eliminado, hay que pararlo y borrarlo. Se puede borrar a la fuerza:
Creando un contenedor con un servidor web
Para lanzar un contenedor con apache en segundo plano:
atlas@olympus:~$ docker run -d --name my-apache-app -p 8080:80 httpd:2.4
28bd87fd47f48201f2805dc8be0a5a4a9698dd0b4289a2ed9ae0c6f11c436775
Pruebo que funciona:
Para ver sus logs:
atlas@olympus:~$ docker logs my-apache-app
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 172.17.0.2. Set the 'ServerName' directive globally to suppress this message
[Fri Jun 10 10:42:47.967351 2022] [mpm_event:notice] [pid 1:tid 140566825770304] AH00489: Apache/2.4.54 (Unix) configured -- resuming normal operations
[Fri Jun 10 10:42:47.967443 2022] [core:notice] [pid 1:tid 140566825770304] AH00094: Command line: 'httpd -D FOREGROUND'
172.17.0.1 - - [10/Jun/2022:10:45:34 +0000] "GET / HTTP/1.1" 200 45
Logs en tiempo real:
Para modificar el index.html
accediendo al contenedor:
atlas@olympus:~$ docker exec -it my-apache-app bash
root@eaee87a6a08f:/usr/local/apache2# cd htdocs/
root@eaee87a6a08f:/usr/local/apache2/htdocs# echo "<h1>Curso Docker</h1>" > index.html
root@eaee87a6a08f:/usr/local/apache2/htdocs# exit
exit
Pruebo que funciona:
Para modificar el index.html
sin acceder al contenedor:
docker exec my-apache-app bash -c 'echo "<h1>Curso Docker 2</h1>" > /usr/local/apache2/htdocs/index.html'
Configuración de contenedores con variables de entorno
Para crear un contenedor con una variable:
atlas@olympus:~$ docker run -it --name prueba -e USUARIO=prueba ubuntu bash
root@cf492c1f8f1a:/# echo $USUARIO
prueba
Para lanzar un MariaDB con una variable:
atlas@olympus:~$ docker run -d --name some-mariadb -e MYSQL_ROOT_PASSWORD=my-secret-pw mariadb
Unable to find image 'mariadb:latest' locally
latest: Pulling from library/mariadb
405f018f9d1d: Already exists
7a85079b8234: Pull complete
579c7ff691b1: Pull complete
4976663b5d6d: Pull complete
169024b1fb13: Pull complete
c0ffe8ce897f: Pull complete
b583c09d23c3: Pull complete
9b9f0c08d08f: Pull complete
9cd51f984586: Pull complete
d9f506bb8aca: Pull complete
24d689f79ba4: Pull complete
Digest: sha256:88fcb7d92c7f61cd885c4d309c98461f3607aa6dbd57a2474be86e1956b36d13
Status: Downloaded newer image for mariadb:latest
fafaba08181c061d5aadbb7f79dda4e2d61cbea6dd883f80f4f51a64cecb5834
atlas@olympus:~$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
fafaba08181c mariadb "docker-entrypoint.s…" 14 seconds ago Up 12 seconds 3306/tcp some-mariadb
eaee87a6a08f httpd:2.4 "httpd-foreground" 7 hours ago Up 7 hours 0.0.0.0:8080->80/tcp my-apache-app
Para ver la variable creada:
atlas@olympus:~$ docker exec -it some-mariadb env
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
HOSTNAME=fafaba08181c
TERM=xterm
MYSQL_ROOT_PASSWORD=my-secret-pw
GOSU_VERSION=1.14
MARIADB_MAJOR=10.8
MARIADB_VERSION=1:10.8.3+maria~jammy
HOME=/root
Para acceder a la BD:
atlas@olympus:~$ docker exec -it some-mariadb bash
root@fafaba08181c:/# mysql -u root -p"$MYSQL_ROOT_PASSWORD"
Welcome to the MariaDB monitor. Commands end with ; or \g.
Your MariaDB connection id is 4
Server version: 10.8.3-MariaDB-1:10.8.3+maria~jammy mariadb.org binary distribution
Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.
Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.
MariaDB [(none)]>
Para acceder a la BD directamente:
atlas@olympus:~$ docker exec -it some-mariadb mysql -u root -p
Enter password:
Welcome to the MariaDB monitor. Commands end with ; or \g.
Your MariaDB connection id is 5
Server version: 10.8.3-MariaDB-1:10.8.3+maria~jammy mariadb.org binary distribution
Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.
Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.
MariaDB [(none)]>
Para eliminar el contenedor anterior:
Para que se pueda acceder a la BD desde el exterior:
atlas@olympus:~$ docker run -d -p 3306:3306 --name some-mariadb -e MYSQL_ROOT_PASSWORD=my-secret-pw mariadb
90b5f9c312cb79a57ca1397f80daa8294f75cf6fad3cf6ae3fed8e427d845fac
Para comprobar que ha funcionado el mapeo de puertos:
atlas@olympus:~$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
90b5f9c312cb mariadb "docker-entrypoint.s…" 2 minutes ago Up 2 minutes 0.0.0.0:3306->3306/tcp some-mariadb
Nos conectamos a la BD del contenedor desde nuestro equipo:
atlas@olympus:~$ mysql -u root -p -h 127.0.0.1
Enter password:
Welcome to the MariaDB monitor. Commands end with ; or \g.
Your MariaDB connection id is 4
Server version: 10.8.3-MariaDB-1:10.8.3+maria~jammy mariadb.org binary distribution
Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.
Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.
MariaDB [(none)]>
Ejercicios introducción
Crear un contenedor con las siguientes características:
- Demonio
- Con la imagen nginx
- Llamado servidor_web
- Acceso por puerto 8181
Pantallazo con creación del contenedor y comprobación de que está funcionando:
Pantallazo accediendo al servidor web:
Pantallazo de tus imágenes locales:
Pantallazo eliminando el contenedor:
Vemos en el listado final de contenedores que ya no existe "servidor_web".
Imágenes
Registros de imágenes: Docker Hub
Estructura de nombre de una imagen:
Gestión de imágenes
Para listar las imágenes locales:
atlas@olympus:~$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
httpd 2.4 acd59370d8fb 2 days ago 144MB
mariadb latest ea81af801379 4 days ago 383MB
ubuntu latest 27941809078c 4 days ago 77.8MB
nginx latest 0e901e68141f 2 weeks ago 142MB
hello-world latest feb5d9fea6a5 8 months ago 13.3kB
Para descargar la última versión de una imagen:
atlas@olympus:~$ docker pull hello-world
Using default tag: latest
latest: Pulling from library/hello-world
2db29710123e: Pull complete
Digest: sha256:80f31da1ac7b312ba29d65080fddf797dd76acfb870e677f390d5acba9741b17
Status: Downloaded newer image for hello-world:latest
docker.io/library/hello-world:latest
Para eliminar imágenes sin contenedores creados:
atlas@olympus:~$ docker rmi hello-world
Untagged: hello-world:latest
Untagged: hello-world@sha256:80f31da1ac7b312ba29d65080fddf797dd76acfb870e677f390d5acba9741b17
Deleted: sha256:feb5d9fea6a5e9606aa995e879d862b825965ba48de054caab5ef356dc6b3412
Deleted: sha256:e07ee1baac5fae6a26f30cabfe54a36d3402f96afda318fe0a96cec4ca393359
Para buscar imágenes en Docker Hub:
atlas@olympus:~$ docker search hello-world
NAME DESCRIPTION STARS OFFICIAL AUTOMATED
hello-world Hello World! (an example of minimal Dockeriz… 1760 [OK]
kitematic/hello-world-nginx A light-weight nginx container that demonstr… 152
tutum/hello-world Image to test docker deployments. Has Apache… 88 [OK]
dockercloud/hello-world Hello World! 19 [OK]
crccheck/hello-world Hello World web server in under 2.5 MB 15 [OK]
vad1mo/hello-world-rest A simple REST Service that echoes back all t… 5 [OK]
ppc64le/hello-world Hello World! (an example of minimal Dockeriz… 2
ansibleplaybookbundle/hello-world-db-apb An APB which deploys a sample Hello World! a… 2 [OK]
thomaspoignant/hello-world-rest-json This project is a REST hello-world API to bu… 1
rancher/hello-world 1
ansibleplaybookbundle/hello-world-apb An APB which deploys a sample Hello World! a… 1 [OK]
businessgeeks00/hello-world-nodejs 0
strimzi/hello-world-producer 0
strimzi/hello-world-consumer 0
koudaiii/hello-world 0
freddiedevops/hello-world-spring-boot 0
strimzi/hello-world-streams 0
tsepotesting123/hello-world 0
armswdev/c-hello-world Simple hello-world C program on Alpine Linux… 0
garystafford/hello-world Simple hello-world Spring Boot service for t… 0 [OK]
kevindockercompany/hello-world 0
rsperling/hello-world3 0
dandando/hello-world-dotnet 0
okteto/hello-world 0
uniplaces/hello-world 0
Para ver información sobre imágenes locales:
atlas@olympus:~$ docker inspect hello-world
[
{
"Id": "sha256:feb5d9fea6a5e9606aa995e879d862b825965ba48de054caab5ef356dc6b3412",
"RepoTags": [
"hello-world:latest"
],
"RepoDigests": [
"hello-world@sha256:80f31da1ac7b312ba29d65080fddf797dd76acfb870e677f390d5acba9741b17"
],
"Parent": "",
"Comment": "",
"Created": "2021-09-23T23:47:57.442225064Z",
"Container": "8746661ca3c2f215da94e6d3f7dfdcafaff5ec0b21c9aff6af3dc379a82fbc72",
"ContainerConfig": {
"Hostname": "8746661ca3c2",
"Domainname": "",
"User": "",
"AttachStdin": false,
"AttachStdout": false,
"AttachStderr": false,
"Tty": false,
"OpenStdin": false,
"StdinOnce": false,
"Env": [
"PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
],
"Cmd": [
"/bin/sh",
"-c",
"#(nop) ",
"CMD [\"/hello\"]"
],
"Image": "sha256:b9935d4e8431fb1a7f0989304ec86b3329a99a25f5efdc7f09f3f8c41434ca6d",
"Volumes": null,
"WorkingDir": "",
"Entrypoint": null,
"OnBuild": null,
"Labels": {}
},
"DockerVersion": "20.10.7",
"Author": "",
"Config": {
"Hostname": "",
"Domainname": "",
"User": "",
"AttachStdin": false,
"AttachStdout": false,
"AttachStderr": false,
"Tty": false,
"OpenStdin": false,
"StdinOnce": false,
"Env": [
"PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
],
"Cmd": [
"/hello"
],
"Image": "sha256:b9935d4e8431fb1a7f0989304ec86b3329a99a25f5efdc7f09f3f8c41434ca6d",
"Volumes": null,
"WorkingDir": "",
"Entrypoint": null,
"OnBuild": null,
"Labels": null
},
"Architecture": "amd64",
"Os": "linux",
"Size": 13256,
"VirtualSize": 13256,
"GraphDriver": {
"Data": {
"MergedDir": "/var/lib/docker/overlay2/d3432ee4a8fdbdb72453b41fabf1ea7d479acb51a60649810de1561a3f241b85/merged",
"UpperDir": "/var/lib/docker/overlay2/d3432ee4a8fdbdb72453b41fabf1ea7d479acb51a60649810de1561a3f241b85/diff",
"WorkDir": "/var/lib/docker/overlay2/d3432ee4a8fdbdb72453b41fabf1ea7d479acb51a60649810de1561a3f241b85/work"
},
"Name": "overlay2"
},
"RootFS": {
"Type": "layers",
"Layers": [
"sha256:e07ee1baac5fae6a26f30cabfe54a36d3402f96afda318fe0a96cec4ca393359"
]
},
"Metadata": {
"LastTagTime": "0001-01-01T00:00:00Z"
}
}
]
¿Cómo se organizan las imágenes?
Para ver el tamaño de las imágenes:
atlas@olympus:~$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
httpd 2.4 acd59370d8fb 2 days ago 144MB
mariadb latest ea81af801379 4 days ago 383MB
ubuntu latest 27941809078c 4 days ago 77.8MB
nginx latest 0e901e68141f 2 weeks ago 142MB
hello-world latest feb5d9fea6a5 8 months ago 13.3kB
Creo un contenedor interactivo y me salgo:
Para visualizar los contenedores con su tamaño:
atlas@olympus:~$ docker ps -a -s
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES SIZE
d3a811e18218 ubuntu "/bin/bash" 14 minutes ago Exited (0) 14 minutes ago contenedor1 5B (virtual 77.8MB)
90b5f9c312cb mariadb "docker-entrypoint.s…" 20 hours ago Exited (255) 17 hours ago 0.0.0.0:3306->3306/tcp some-mariadb 0B (virtual 383MB)
45c6f4b0dbcc ubuntu "echo 'Hello world'" 44 hours ago Exited (0) 44 hours ago competent_davinci 0B (virtual 77.8MB)
El tamaño real del contenedor es casi nulo. El virtual es el que comparte con la imagen de ubuntu.
Volvemos a acceder al contenedor y creamos un fichero:
atlas@olympus:~$ docker start contenedor1
contenedor1
atlas@olympus:~$ docker attach contenedor1
root@d3a811e18218:/# echo "00000000000000000">file.txt
root@d3a811e18218:/# exit
exit
Vemos que ha crecido el tamaño del contenedor:
atlas@olympus:~$ docker ps -a -s
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES SIZE
d3a811e18218 ubuntu "/bin/bash" 41 minutes ago Exited (0) 6 minutes ago contenedor1 62B (virtual 77.8MB)
90b5f9c312cb mariadb "docker-entrypoint.s…" 21 hours ago Exited (255) 17 hours ago 0.0.0.0:3306->3306/tcp some-mariadb 0B (virtual 383MB)
45c6f4b0dbcc ubuntu "echo 'Hello world'" 45 hours ago Exited (0) 44 hours ago competent_davinci 0B (virtual 77.8MB)
Para ver información sobre las capas de una imagen:
Creación de contenedores desde imágenes
Todas las imágenes tienen definidas un proceso que se ejecuta por defecto, pero en la mayoría de los casos podemos indicar un proceso al crear un contenedor.
En la imagen ubuntu el proceso por defecto es bash, por lo tanto podemos ejecutar:
También podemos indicar el comando a ejecutar al crear un contenedor:
La imagen httpd:2.4 ejecuta un servidor web por defecto:
atlas@olympus:~$ docker run -d --name my-apache-app -p 8080:80 httpd:2.4
d5d49317f2a978a8ee163db794f43a6bc09b1594444fd9a575e80ddecf04e469
Ejemplo: Desplegando la aplicación MediaWiki
Para instalar la última versión:
Comprobamos que funciona y es efectivamente la última versión:
Instalamos otra versión de MediaWiki, la 1.36.3:
Comprobamos que funciona y es efectivamente la versión indicada:
Finalmente instalamos otra versión:
Comprobamos que funciona y es efectivamente la versión indicada:
A lo largo de este ejemplo hemos podido comprobar que las capas que ya existen no se las vuelve a descargar.
Ejercicios imágenes
Servidor web
Lanzar un contenedor con características:
- Imagen php:7.4-apache
- Llamado web
- Puerto 8000
atlas@olympus:~$ docker run -d -p 8000:80 --name web php:7.4-apache
Unable to find image 'php:7.4-apache' locally
7.4-apache: Pulling from library/php
42c077c10790: Already exists
8934009a9160: Already exists
5357ac116991: Already exists
54ae63894b5a: Already exists
772088206f85: Already exists
3b81c5474649: Already exists
c62a528527ae: Already exists
344c792709d4: Already exists
ef9638273c35: Already exists
4ec70638e42f: Already exists
5a0f65f5bb3b: Already exists
55578a5ce5e8: Already exists
f1dd85b4dfa5: Already exists
Digest: sha256:c65cd02abef32e0ab1558788dbcf855e6dde301159da14651c844f533b34a411
Status: Downloaded newer image for php:7.4-apache
a46be0b60d37a4e009c0b40934aafa72332a1da8e04c6dec8712b8354630d161
Muestro que se está ejecutando:
atlas@olympus:~$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
a46be0b60d37 php:7.4-apache "docker-php-entrypoi…" 3 minutes ago Up 3 minutes 0.0.0.0:8000->80/tcp web
Colocar en /var/www/html
un index.html
con contenido <h1>HOLA SOY ADRIAN JARAMILLO</h1>
:
Muestro que ha funcionado:
Colocar en /var/www/html
un index.php
con contenido <?php echo phpinfo(); ?>
:
Muestro que ha funcionado:
Muestro el tamaño del contenedor web
tras crear los dos ficheros:
Servidor BD
Lanzar un contenedor con características:
- Llamado bbdd
- Imagen mariadb
- Puerto 3336
- Contraseña root: root
- Base de datos: prueba
- Usuario: invitado
- Contraseña: invitado
docker run -d -p 3336:3306 --name bbdd -e MARIADB_ROOT_PASSWORD=root -e MARIADB_DATABASE=prueba -e MARIADB_USER=invitado -e MARIADB_PASSWORD=invitado mariadb
Mostrar el acceso a la BD desde nuestro ordenador con el usuario invitado, y mostrar la BD prueba:
Mostrar que no se puede borrar la imagen mariadb mientras el contenedor bbdd
existe:
Almacenamiento
Los contenedores son efímeros
Los datos de los contenedores sobreviven a paradas pero no a destrucciones.
Ejemplo:
atlas@olympus:~$ docker run -d --name my-apache-app -p 8080:80 httpd:2.4
4dbe1355067367db8a435256af733a1405cab06de21b61cd67c269d0891eb48c
atlas@olympus:~$ docker exec my-apache-app bash -c 'echo "<h1>Hola</h1>" > /usr/local/apache2/htdocs/index.html'
atlas@olympus:~$ curl http://localhost:8080
<h1>Hola</h1>
atlas@olympus:~$ docker rm -f my-apache-app
my-apache-app
atlas@olympus:~$ docker run -d --name my-apache-app -p 8080:80 httpd:2.4
be4204135657e6ddbeccc2d8205e5977b0fc771bddf932a21a3e0bc9b5df2b68
atlas@olympus:~$ curl http://localhost:8080
<html><body><h1>It works!</h1></body></html>
Nos damos cuenta de que el index.html
modificado se pierde, y al lanzar otro contenedor vuelve al contenido original.
Volúmenes docker y bind mount
Volúmenes
Se guardan en /var/lib/docker/volumes
Para crear un volumen:
Para eliminar un volumen:
Para eliminar volúmenes que no están siendo usados por ningún contenedor:
atlas@olympus:~$ docker volume prune
WARNING! This will remove all local volumes not used by at least one container.
Are you sure you want to continue? [y/N] y
Deleted Volumes:
ee50d8c9aa7de5fda336d094a3bb25566667f88a4c9864e3b1fd8e3bd619b0d8
6a3bd1b8cbc0029c01daf50080d3d682918e6f3fed56164914a81df7c09535dd
Total reclaimed space: 295MB
Para listar volúmenes:
atlas@olympus:~$ docker volume ls
DRIVER VOLUME NAME
local f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3
Para ver información sobre volúmenes:
atlas@olympus:~$ docker volume inspect f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3
[
{
"CreatedAt": "2022-06-12T13:34:02+02:00",
"Driver": "local",
"Labels": null,
"Mountpoint": "/var/lib/docker/volumes/f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3/_data",
"Name": "f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3",
"Options": null,
"Scope": "local"
}
]
Bind mounts
Esto es mapear/montar directorios/ficheros de mi sistema de ficheros con el contenedor.
Asociando almacenamiento a los contenedores: volúmenes docker
Ya sean volúmenes o bind mount, usaremos las mismas flags de docker run
:
--volume
o-v
--mount
Creamos un volumen:
Lanzamos un contenedor con el volumen asociado y modificamos el index.html
:
atlas@olympus:~$ docker run -d --name my-apache-app --mount type=volume,src=miweb,dst=/usr/local/apache2/htdocs -p 8080:80 httpd:2.4
4192e7c4df28ab3a7df706fa5eaad3c9fd893379a8be9705e1b714de80d284c2
atlas@olympus:~$ docker exec my-apache-app bash -c 'echo "<h1>Hola</h1>" > /usr/local/apache2/htdocs/index.html'
atlas@olympus:~$ curl http://localhost:8080
<h1>Hola</h1>
atlas@olympus:~$ docker rm -f my-apache-app
my-apache-app
Tras borrarlo creamos otro con el volumen asociado, pero usamos -v
:
atlas@olympus:~$ docker run -d --name my-apache-app -v miweb:/usr/local/apache2/htdocs -p 8080:80 httpd:2.4
a115083f365e64e138c2fd9adf944382abff30318f685b75c8368d1d2802a89b
Comprobamos que no se ha perdido la información:
Si no indicamos volumen se crea uno nuevo:
atlas@olympus:~$ docker volume ls
DRIVER VOLUME NAME
local f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3
atlas@olympus:~$ docker run -d --name my-apache-app --mount type=volume,dst=/usr/local/apache2/htdocs -p 8080:80 httpd:2.4
151f85c244bb81b8b26734c612b3b584f76dd3638b00210a0d6b30ecf4b35066
atlas@olympus:~$ docker volume ls
DRIVER VOLUME NAME
local 65eb5fc7fc9f541f1dd35effc2e456e615f6ef51670ef07a9971d2278c9dd4ee
local f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3
Si usamos -v
y decimos un nombre se crea un volumen nuevo:
atlas@olympus:~$ docker run -d --name my-apache-app -v wwwroot:/usr/local/apache2/htdocs -p 8080:80 httpd:2.4
c22f12f358f1f066c33d067b3492200829cce6af11cbde07724b8058caebfc3b
atlas@olympus:~$ docker volume ls
DRIVER VOLUME NAME
local 65eb5fc7fc9f541f1dd35effc2e456e615f6ef51670ef07a9971d2278c9dd4ee
local f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3
local wwwroot
Tanto volúmenes como bind mount sobreescribirán la carpeta destino del contenedor.
Asociando almacenamiento a los contenedores: bind mount
Creamos un directorio en nuestra máquina con un index.html
:
atlas@olympus:~$ mkdir web
atlas@olympus:~$ cd web
atlas@olympus:~/web$ echo "<h1>Hola</h1>" > index.html
Montamos ese directorio en un contenedor con -v
:
atlas@olympus:~/web$ docker run -d --name my-apache-app -v /home/atlas/web:/usr/local/apache2/htdocs -p 8080:80 httpd:2.4
426d7ef55bb658c87964fd7a26589e6325163549f1053930076b0696e0751550
Comprobamos que estamos sirviendo el fichero de nuestro directorio:
Eliminamos el contenedor y creamos otro con el directorio montado, esta vez usando --mount
:
atlas@olympus:~$ docker rm -f my-apache-app
my-apache-app
atlas@olympus:~$ docker run -d --name my-apache-app --mount type=bind,src=/home/atlas/web,dst=/usr/local/apache2/htdocs -p 8080:80 httpd:2.4
d892a24a44f42d967a3cffb218641d29812fbf258c158a676cf3fff821f9eb7e
atlas@olympus:~$ curl http://localhost:8080
<h1>Hola</h1>
Podemos modificar el index.html
aunque esté montado en el contenedor:
atlas@olympus:~$ echo "<h1>Adios</h1>" > web/index.html
atlas@olympus:~$ curl http://localhost:8080
<h1>Adios</h1>
Si usamos bind mount con -v
y la carpeta origen no existe, se crea, pero estará vacía.
Si usamos bind mount con --mount
y la carpeta origen no existe, dará un error.
Ejemplo 1: Contenedor Nextcloud con almacenamiento persistente
Con volumen
Creo uno:
Lanzo un contenedor enlazado con el volumen:
atlas@olympus:~$ docker run -d -p 80:80 -v nextcloud:/var/www/html --name contenedor_nextcloud nextcloud
cc2e756082a06500578913dbaffdf36d6cd92e18d029f2a737737c1455a80b7d
Accedemos, hacemos la instalación, y subimos un fichero:
Eliminamos el contenedor y creamos otro con el mismo volumen:
atlas@olympus:~$ docker rm -f contenedor_nextcloud
contenedor_nextcloud
atlas@olympus:~$ docker run -d -p 80:80 -v nextcloud:/var/www/html --name contenedor_nextcloud nextcloud
b59bf01aa8794df605ad0546571bfbc1204cb4e2dc1b74201954c122e84f5206
Accedemos de nuevo y comprobamos que todo sigue igual:
Con bind mount
Crearemos un directorio que luego montaremos en el contenedor:
Creamos el contenedor:
atlas@olympus:~$ docker run -d -p 80:80 -v /home/atlas/datos_nextcloud:/var/www/html --name contenedor_nextcloud nextcloud
ee29347f1eafd00ba329333b232bb9020457783de5fe9d1ae561fa7fb63c85f8
Volvemos a acceder, instalamos, y subimos un fichero:
Al usar bind mount tenemos acceso al directorio:
atlas@olympus:~$ cd datos_nextcloud/
atlas@olympus:~/datos_nextcloud$ ls -la
total 184
drwxr-xr-x 15 www-data root 4096 Jun 12 19:34 .
drwxr-xr-x 38 atlas atlas 4096 Jun 12 19:30 ..
drwxr-xr-x 43 www-data root 4096 Jun 12 19:34 3rdparty
drwxr-xr-x 48 www-data root 4096 Jun 12 19:34 apps
-rw-r--r-- 1 www-data root 19327 Jun 12 19:34 AUTHORS
drwxr-xr-x 2 www-data root 4096 Jun 12 19:38 config
-rw-r--r-- 1 www-data root 3924 Jun 12 19:34 console.php
-rw-r--r-- 1 www-data root 34520 Jun 12 19:34 COPYING
drwxr-xr-x 22 www-data root 4096 Jun 12 19:34 core
-rw-r--r-- 1 www-data root 6260 Jun 12 19:34 cron.php
drwxr-xr-x 2 www-data root 4096 Jun 12 19:34 custom_apps
drwxrwx--- 5 www-data root 4096 Jun 12 19:41 data
drwxr-xr-x 2 www-data root 12288 Jun 12 19:34 dist
-rw-r--r-- 1 www-data root 4387 Jun 12 19:38 .htaccess
-rw-r--r-- 1 www-data root 156 Jun 12 19:34 index.html
-rw-r--r-- 1 www-data root 3456 Jun 12 19:34 index.php
drwxr-xr-x 6 www-data root 4096 Jun 12 19:34 lib
-rwxr-xr-x 1 www-data root 283 Jun 12 19:34 occ
drwxr-xr-x 2 www-data root 4096 Jun 12 19:34 ocm-provider
drwxr-xr-x 2 www-data root 4096 Jun 12 19:34 ocs
drwxr-xr-x 2 www-data root 4096 Jun 12 19:34 ocs-provider
-rw-r--r-- 1 www-data root 3139 Jun 12 19:34 public.php
-rw-r--r-- 1 www-data root 5340 Jun 12 19:34 remote.php
drwxr-xr-x 4 www-data root 4096 Jun 12 19:34 resources
-rw-r--r-- 1 www-data root 26 Jun 12 19:34 robots.txt
-rw-r--r-- 1 www-data root 2452 Jun 12 19:34 status.php
drwxr-xr-x 3 www-data root 4096 Jun 12 19:34 themes
-rw-r--r-- 1 www-data root 101 Jun 12 19:34 .user.ini
-rw-r--r-- 1 www-data root 382 Jun 12 19:34 version.php
Si eliminamos el contenedor y lo volvemos a crear con el mismo directorio bind mount, todo seguirá igual:
atlas@olympus:~$ docker rm -f contenedor_nextcloud
contenedor_nextcloud
atlas@olympus:~$ docker run -d -p 80:80 -v /home/atlas/datos_nextcloud:/var/www/html --name contenedor_nextcloud nextcloud
74099565d46f4ddb28547a071349a487bd511ac5e2cc47b3f29d72a6cfedd7ab
Ejemplo 2: Contenedor MariaDB con almacenamiento persistente
Lanzamos el contenedor:
atlas@olympus:~$ docker run --name some-mariadb -v /home/atlas/datadir:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=my-secret-pw -d mariadb
d12a51b521342a15b3b82cd59bab2d9de15946e5cd77a1d9149e892610121224
El directorio /home/atlas/datadir
se creará automáticamente.
Si borramos el contenedor, lo volvemos a crear, e indicamos ese directorio como bind mount, todo seguirá igual.
atlas@olympus:~$ cd datadir/
atlas@olympus:~/datadir$ ls -la
total 139260
drwxr-xr-x 5 systemd-coredump systemd-coredump 4096 Jun 12 20:04 .
drwxr-xr-x 39 atlas atlas 4096 Jun 12 20:04 ..
-rw-rw---- 1 systemd-coredump systemd-coredump 16719872 Jun 12 20:04 aria_log.00000001
-rw-rw---- 1 systemd-coredump systemd-coredump 52 Jun 12 20:04 aria_log_control
-rw-rw---- 1 systemd-coredump systemd-coredump 9 Jun 12 20:04 ddl_recovery.log
-rw-rw---- 1 systemd-coredump systemd-coredump 868 Jun 12 20:04 ib_buffer_pool
-rw-rw---- 1 systemd-coredump systemd-coredump 12582912 Jun 12 20:04 ibdata1
-rw-rw---- 1 systemd-coredump systemd-coredump 100663296 Jun 12 20:06 ib_logfile0
-rw-rw---- 1 systemd-coredump systemd-coredump 12582912 Jun 12 20:04 ibtmp1
-rw-rw---- 1 systemd-coredump systemd-coredump 0 Jun 12 20:04 multi-master.info
drwx------ 2 systemd-coredump systemd-coredump 4096 Jun 12 20:04 mysql
-rw-r--r-- 1 systemd-coredump systemd-coredump 14 Jun 12 20:04 mysql_upgrade_info
drwx------ 2 systemd-coredump systemd-coredump 4096 Jun 12 20:04 performance_schema
drwx------ 2 systemd-coredump systemd-coredump 12288 Jun 12 20:04 sys
atlas@olympus:~/datadir$ docker exec -it some-mariadb bash -c 'mysql -uroot -p$MYSQL_ROOT_PASSWORD'
Welcome to the MariaDB monitor. Commands end with ; or \g.
Your MariaDB connection id is 3
Server version: 10.8.3-MariaDB-1:10.8.3+maria~jammy mariadb.org binary distribution
Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.
Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.
MariaDB [(none)]> create database prueba;
Query OK, 1 row affected (0.001 sec)
MariaDB [(none)]> quit
Bye
atlas@olympus:~/datadir$ docker rm -f some-mariadb
some-mariadb
atlas@olympus:~/datadir$ docker run --name some-mariadb -v /home/atlas/datadir:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=my-secret-pw -d mariadb
84fb33568b2db708442f4099d6a8cf2636a2edb676630acbb7e71ca33f4ae2cc
atlas@olympus:~/datadir$ docker exec -it some-mariadb bash -c 'mysql -uroot -p$MYSQL_ROOT_PASSWORD'
Welcome to the MariaDB monitor. Commands end with ; or \g.
Your MariaDB connection id is 3
Server version: 10.8.3-MariaDB-1:10.8.3+maria~jammy mariadb.org binary distribution
Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.
Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.
MariaDB [(none)]> show databases;
+--------------------+
| Database |
+--------------------+
| information_schema |
| mysql |
| performance_schema |
| prueba |
| sys |
+--------------------+
5 rows in set (0.001 sec)
MariaDB [(none)]>
Otros usos del almacenamiento
Compartir información entre contenedores
Tendremos un contenedor principal con un servidor web sirviendo un index.html
. El segundo contenedor irá actualizándolo.
Creamos el volumen:
Lanzamos el primer contenedor con el volumen montado en su DocumentRoot
, en solo lectura (ro):
atlas@olympus:~$ docker run -d -p 8181:80 --name contenedor1 -v datos_compartidos:/var/www/html:ro php:7.4-apache
2c2eb3c74624156a94360ec93b431193a4eb39d9f8ce51f54ad5c7618e9b4fe5
Lanzamos el segundo contenedor, que irá modificando index.html
en el volumen cada segundo:
atlas@olympus:~$ docker run -d --name contenedor2 -v datos_compartidos:/srv debian bash -c "while true; do date >> /srv/index.html;sleep 1;done"
Unable to find image 'debian:latest' locally
latest: Pulling from library/debian
e756f3fdd6a3: Pull complete
Digest: sha256:3f1d6c17773a45c97bd8f158d665c9709d7b29ed7917ac934086ad96f92e4510
Status: Downloaded newer image for debian:latest
33aac5ea223daf385d736bc43ea73b5e3dc0f033c050b968224b9f2a5d187f99
Accedemos al servidor web y comprobamos que funciona:
También se podría haber hecho con bind mount:
atlas@olympus:~$ docker run -d -p 8181:80 --name contenedor1 -v /home/atlas/compartido:/var/www/html:ro php:7.4-apache
af6c26e17a3857d54c3c35363622412cb2381bed3f1c981add1ff4ea10713f97
atlas@olympus:~$ docker run -d --name contenedor2 -v /home/atlas/compartido:/srv debian bash -c "while true; do date >> /srv/index.html;sleep 1;done"
f4b562b1e9c38afb49b0e830e9dc9f78d3d964b7741b6937282672f7a1256247
Comprobamos que sigue funcionando:
Podríamos ver el fichero ~/compartido/index.html
en nuestra máquina:
atlas@olympus:~$ ls -la compartido/
total 20
drwxr-xr-x 2 root root 4096 Jun 12 21:04 .
drwxr-xr-x 40 atlas atlas 4096 Jun 12 21:03 ..
-rw-r--r-- 1 root root 9280 Jun 12 21:09 index.html
Comprobar compatibilidad de código entre distintas versiones de un lenguaje de programación
Creamos el directorio codigo
:
Dentro creamos un index.php
con el siguiente código:
<?php
// Funciona bien en php5 ya que list hace la asignación desde el último al primero
$info = array('cafeÃna','marrón', 'café');
// Enumerar todas las variables
list($datos[], $datos[], $datos[]) = $info;
echo "El $datos[0] es $datos[1] y la $datos[2] lo hace especial.\n";
?>
Lanzamos dos contenedores sirviendo este código pero con imágenes distintas y puertos distintos:
atlas@olympus:~$ docker run -d -p 8081:80 --name php56 -v /home/atlas/codigo:/var/www/html:ro php:5.6-apache
Unable to find image 'php:5.6-apache' locally
5.6-apache: Pulling from library/php
5e6ec7f28fb7: Pull complete
cf165947b5b7: Pull complete
7bd37682846d: Pull complete
99daf8e838e1: Pull complete
ae320713efba: Pull complete
ebcb99c48d8c: Pull complete
9867e71b4ab6: Pull complete
936eb418164a: Pull complete
bc298e7adaf7: Pull complete
ccd61b587bcd: Pull complete
b2d4b347f67c: Pull complete
56e9dde34152: Pull complete
9ad99b17eb78: Pull complete
Digest: sha256:0a40fd273961b99d8afe69a61a68c73c04bc0caa9de384d3b2dd9e7986eec86d
Status: Downloaded newer image for php:5.6-apache
368c1d95a662014540b74505b892d5f0e9df214aa6708c9a10c132bb6ce03972
atlas@olympus:~$ docker run -d -p 8082:80 --name php74 -v /home/atlas/codigo:/var/www/html:ro php:7.4-apache
ae94d1294cdc62c9af7d71c383c63be295ede4eb626907cd037124a8b5f8fc47
Ya podemos acceder a cada puerto y comparar:
Ejercicios almacenamiento
Creo los siguientes volúmenes:
atlas@olympus:~$ docker volume create volumen_datos
volumen_datos
atlas@olympus:~$ docker volume create volumen_web
volumen_web
Lanzo el primer contenedor:
Lanzo el segundo contenedor:
Paramos y borramos c2
, luego borramos volumen_datos
:
atlas@olympus:~$ docker stop c2
c2
atlas@olympus:~$ docker rm c2
c2
atlas@olympus:~$ docker volume rm volumen_datos
volumen_datos
Creamos un index.html
en c1
y comprobamos que funciona:
Borramos c1
y creamos c3
:
atlas@olympus:~$ docker stop c1
c1
atlas@olympus:~$ docker rm c1
c1
atlas@olympus:~$ docker run -d -p 8081:80 --name c3 -v volumen_web:/var/www/html php:7.4-apache
7c401c786a6aac6aa4c1ec8874066fb63b943554b273637e996ef4d5b6fc6e2a
Comprobamos que el index.html
anterior sigue funcionando en c3
:
Redes
Introducción a las redes en Docker
Lanzo un contenedor que se borrará al pararse (--rm):
Para ver la IP asignada:
atlas@olympus:~$ docker inspect -f '{{range.NetworkSettings.Networks}}{{.IPAddress}}{{end}}' contenedor1
172.17.0.2
El bridge docker0
en nuestro host es al que se conectan todos los contenedores por defecto:
Docker nos modifica el cortafuegos:
atlas@olympus:~$ sudo iptables -L -n
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain FORWARD (policy DROP)
target prot opt source destination
DOCKER-USER all -- 0.0.0.0/0 0.0.0.0/0
DOCKER-ISOLATION-STAGE-1 all -- 0.0.0.0/0 0.0.0.0/0
ACCEPT all -- 0.0.0.0/0 0.0.0.0/0 ctstate RELATED,ESTABLISHED
DOCKER all -- 0.0.0.0/0 0.0.0.0/0
ACCEPT all -- 0.0.0.0/0 0.0.0.0/0
ACCEPT all -- 0.0.0.0/0 0.0.0.0/0
Chain OUTPUT (policy ACCEPT)
target prot opt source destination
Chain DOCKER (1 references)
target prot opt source destination
Chain DOCKER-ISOLATION-STAGE-1 (1 references)
target prot opt source destination
DOCKER-ISOLATION-STAGE-2 all -- 0.0.0.0/0 0.0.0.0/0
RETURN all -- 0.0.0.0/0 0.0.0.0/0
Chain DOCKER-ISOLATION-STAGE-2 (1 references)
target prot opt source destination
DROP all -- 0.0.0.0/0 0.0.0.0/0
RETURN all -- 0.0.0.0/0 0.0.0.0/0
Chain DOCKER-USER (1 references)
target prot opt source destination
RETURN all -- 0.0.0.0/0 0.0.0.0/0
atlas@olympus:~$ sudo iptables -L -n -t nat
Chain PREROUTING (policy ACCEPT)
target prot opt source destination
DOCKER all -- 0.0.0.0/0 0.0.0.0/0 ADDRTYPE match dst-type LOCAL
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain OUTPUT (policy ACCEPT)
target prot opt source destination
DOCKER all -- 0.0.0.0/0 !127.0.0.0/8 ADDRTYPE match dst-type LOCAL
Chain POSTROUTING (policy ACCEPT)
target prot opt source destination
MASQUERADE all -- 172.17.0.0/16 0.0.0.0/0
Chain DOCKER (2 references)
target prot opt source destination
RETURN all -- 0.0.0.0/0 0.0.0.0/0
Tipos de redes en Docker
Para listar las redes:
atlas@olympus:~$ docker network ls
NETWORK ID NAME DRIVER SCOPE
cefa7428778f bridge bridge local
34d0a5b2368f host host local
9e2bf2980f1b none null local
Por defecto los contenedores se conectan a bridge
:
En la tipo host
el contenedor ofrece los servicios en la IP y puertos del anfitrión. No tiene ip propia:
atlas@olympus:~$ docker run -d --name mi_servidor --network host josedom24/aplicacionweb:v1
Unable to find image 'josedom24/aplicacionweb:v1' locally
v1: Pulling from josedom24/aplicacionweb
c5e155d5a1d1: Pull complete
f2b76f8f3462: Pull complete
2e8f82335e4d: Pull complete
Digest: sha256:6c28c9bbb10ea66f08c27377bf35cbf23b6bf64f1cc71b20dcd0d39686835796
Status: Downloaded newer image for josedom24/aplicacionweb:v1
89950cbe5d6f29c9f24fac00b720cf70671396f74770d2c2d36f14ae626b7a31
atlas@olympus:~$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
89950cbe5d6f josedom24/aplicacionweb:v1 "/usr/sbin/apache2ct…" 37 seconds ago Up 36 seconds mi_servidor
Podemos acceder localmente al contenedor, sin mapeo:
La red none
no asigna IP y aísla a los contenedores, solo da loopback. Se usa para batch jobs.
Gestionando las redes en docker
Bridge docker0
por defecto ≠ Bridges definidos por el usuario.
Los contenedores en producción deben estar en bridges de usuario, son mejores.
Para listar redes:
atlas@olympus:~$ docker network ls
NETWORK ID NAME DRIVER SCOPE
cefa7428778f bridge bridge local
34d0a5b2368f host host local
9e2bf2980f1b none null local
Para crear redes:
atlas@olympus:~$ docker network create red1
dcec4de396e9802627a000d813e5cc65da4f0992a9cf5ace62eff12f13735da5
atlas@olympus:~$ docker network create -d bridge --subnet 172.24.0.0/16 --gateway 172.24.0.1 red2
e6cacc4df914f5cb9de6b336679ec1ed7e804407f0e56968c74a4a3e7e7a8deb
atlas@olympus:~$ docker network ls
NETWORK ID NAME DRIVER SCOPE
cefa7428778f bridge bridge local
34d0a5b2368f host host local
9e2bf2980f1b none null local
dcec4de396e9 red1 bridge local
e6cacc4df914 red2 bridge local
Para borrar redes:
atlas@olympus:~$ docker network rm red1
red1
atlas@olympus:~$ docker network prune
WARNING! This will remove all custom networks not used by at least one container.
Are you sure you want to continue? [y/N] y
Deleted Networks:
red2
Para ver información de una red:
atlas@olympus:~$ docker network inspect bridge
[
{
"Name": "bridge",
"Id": "cefa7428778f2b0a5af1617a3659829650226ea874cb037d71efd441d80a8a79",
"Created": "2022-06-13T17:40:22.758388059+02:00",
"Scope": "local",
"Driver": "bridge",
"EnableIPv6": false,
"IPAM": {
"Driver": "default",
"Options": null,
"Config": [
{
"Subnet": "172.17.0.0/16",
"Gateway": "172.17.0.1"
}
]
},
"Internal": false,
"Attachable": false,
"Ingress": false,
"ConfigFrom": {
"Network": ""
},
"ConfigOnly": false,
"Containers": {},
"Options": {
"com.docker.network.bridge.default_bridge": "true",
"com.docker.network.bridge.enable_icc": "true",
"com.docker.network.bridge.enable_ip_masquerade": "true",
"com.docker.network.bridge.host_binding_ipv4": "0.0.0.0",
"com.docker.network.bridge.name": "docker0",
"com.docker.network.driver.mtu": "1500"
},
"Labels": {}
}
]
Cada red que creamos genera un bridge como podemos ver:
Uso de la red bridge por defecto
Manera no recomendada. Usaremos el obsoleto --link
.
Lanzo un contenedor:
atlas@olympus:~$ docker run -d --name servidor_mariadb \
-e MYSQL_DATABASE=mi_basededatos \
-e MYSQL_USER=usuario \
-e MYSQL_PASSWORD=asdasd \
-e MYSQL_ROOT_PASSWORD=asdasd \
mariadb
026b003f91c9289fd2d0c1da284057b77607ab62b218321630e887675fddf148
Lanzo otro contenedor enlazado con el anterior:
atlas@olympus:~$ docker run -d --name servidor_web --link servidor_mariadb:mariadb nginx
6336b40e133735e408e5b043763e5eeefea2c51f35a3447d3167fcfed17d6a0f
El enlace se hace por resolución estática:
atlas@olympus:~$ docker exec servidor_web cat /etc/hosts
127.0.0.1 localhost
::1 localhost ip6-localhost ip6-loopback
fe00::0ip6-localnet
ff00::0ip6-mcastprefix
ff02::1ip6-allnodes
ff02::2ip6-allrouters
172.17.0.2 mariadb 026b003f91c9 servidor_mariadb
172.17.0.3 6336b40e1337
El DNS del contenedor es el mismo que el de nuestro host = las resoluciones no se hacen con un DNS:
atlas@olympus:~$ docker exec servidor_web cat /etc/resolv.conf
# Generated by NetworkManager
nameserver 8.8.8.8
nameserver 8.8.4.4
Se comparten variables:
atlas@olympus:~$ docker exec servidor_web env
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
HOSTNAME=6336b40e1337
MARIADB_PORT=tcp://172.17.0.2:3306
MARIADB_PORT_3306_TCP=tcp://172.17.0.2:3306
MARIADB_PORT_3306_TCP_ADDR=172.17.0.2
MARIADB_PORT_3306_TCP_PORT=3306
MARIADB_PORT_3306_TCP_PROTO=tcp
MARIADB_NAME=/servidor_web/mariadb
MARIADB_ENV_MYSQL_DATABASE=mi_basededatos
MARIADB_ENV_MYSQL_USER=usuario
MARIADB_ENV_MYSQL_PASSWORD=asdasd
MARIADB_ENV_MYSQL_ROOT_PASSWORD=asdasd
MARIADB_ENV_GOSU_VERSION=1.14
MARIADB_ENV_MARIADB_MAJOR=10.8
MARIADB_ENV_MARIADB_VERSION=1:10.8.3+maria~jammy
NGINX_VERSION=1.21.6
NJS_VERSION=0.7.3
PKG_RELEASE=1~bullseye
HOME=/root
Uso de las redes bridge definidas por el usuario
Para crear una:
atlas@olympus:~$ docker network create red1
15154211dbeb52ed33a98e45bc9220fa6ec8dd266d72bd8947188a47ac1f3192
Si no indicamos direccionamiento, docker lo asigna automáticamente:
atlas@olympus:~$ docker network inspect red1
[
{
"Name": "red1",
"Id": "15154211dbeb52ed33a98e45bc9220fa6ec8dd266d72bd8947188a47ac1f3192",
"Created": "2022-06-13T20:20:57.861626406+02:00",
"Scope": "local",
"Driver": "bridge",
"EnableIPv6": false,
"IPAM": {
"Driver": "default",
"Options": {},
"Config": [
{
"Subnet": "172.21.0.0/16",
"Gateway": "172.21.0.1"
}
]
},
"Internal": false,
"Attachable": false,
"Ingress": false,
"ConfigFrom": {
"Network": ""
},
"ConfigOnly": false,
"Containers": {},
"Options": {},
"Labels": {}
}
]
Conectaremos dos contenedores a esa red:
atlas@olympus:~$ docker run -d --name my-apache-app --network red1 -p 8080:80 httpd:2.4
ff7e218f3527e116d05b77c6e858b0118e49991fb71bc342b502a60a6d533a59
Comprobaremos la resolución DNS:
atlas@olympus:~$ docker run -it --name contenedor1 --network red1 debian bash
root@646845be5f23:/# apt update
Get:1 http://security.debian.org/debian-security bullseye-security InRelease [44.1 kB]
Get:2 http://deb.debian.org/debian bullseye InRelease [116 kB]
Get:3 http://deb.debian.org/debian bullseye-updates InRelease [39.4 kB]
Get:4 http://deb.debian.org/debian bullseye/main amd64 Packages [8182 kB]
Get:5 http://security.debian.org/debian-security bullseye-security/main amd64 Packages [154 kB]
Get:6 http://deb.debian.org/debian bullseye-updates/main amd64 Packages [2592 B]
Fetched 8539 kB in 39s (218 kB/s)
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
1 package can be upgraded. Run 'apt list --upgradable' to see it.
root@646845be5f23:/# apt install dnsutils -y
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
The following additional packages will be installed:
bind9-dnsutils bind9-host bind9-libs libbsd0 libedit2 libfstrm0 libicu67 libjson-c5 liblmdb0 libmaxminddb0 libmd0 libprotobuf-c1 libuv1 libxml2
Suggested packages:
mmdb-bin
The following NEW packages will be installed:
bind9-dnsutils bind9-host bind9-libs dnsutils libbsd0 libedit2 libfstrm0 libicu67 libjson-c5 liblmdb0 libmaxminddb0 libmd0 libprotobuf-c1 libuv1 libxml2
0 upgraded, 15 newly installed, 0 to remove and 1 not upgraded.
Need to get 12.2 MB of archives.
After this operation, 42.3 MB of additional disk space will be used.
Selecting previously unselected package libicu67:amd64.
Preparing to unpack .../06-libicu67_67.1-7_amd64.deb ...
Unpacking libicu67:amd64 (67.1-7) ...
Selecting previously unselected package libxml2:amd64.
Preparing to unpack .../07-libxml2_2.9.10+dfsg-6.7+deb11u2_amd64.deb ...
Unpacking libxml2:amd64 (2.9.10+dfsg-6.7+deb11u2) ...
Selecting previously unselected package bind9-libs:amd64.
Preparing to unpack .../08-bind9-libs_1%3a9.16.27-1~deb11u1_amd64.deb ...
Unpacking bind9-libs:amd64 (1:9.16.27-1~deb11u1) ...
Selecting previously unselected package bind9-host.
Preparing to unpack .../09-bind9-host_1%3a9.16.27-1~deb11u1_amd64.deb ...
Unpacking bind9-host (1:9.16.27-1~deb11u1) ...
Selecting previously unselected package libmd0:amd64.
Preparing to unpack .../10-libmd0_1.0.3-3_amd64.deb ...
Unpacking libmd0:amd64 (1.0.3-3) ...
Selecting previously unselected package libbsd0:amd64.
Preparing to unpack .../11-libbsd0_0.11.3-1_amd64.deb ...
Unpacking libbsd0:amd64 (0.11.3-1) ...
Selecting previously unselected package libedit2:amd64.
Preparing to unpack .../12-libedit2_3.1-20191231-2+b1_amd64.deb ...
Unpacking libedit2:amd64 (3.1-20191231-2+b1) ...
Selecting previously unselected package bind9-dnsutils.
Preparing to unpack .../13-bind9-dnsutils_1%3a9.16.27-1~deb11u1_amd64.deb ...
Unpacking bind9-dnsutils (1:9.16.27-1~deb11u1) ...
Selecting previously unselected package dnsutils.
Preparing to unpack .../14-dnsutils_1%3a9.16.27-1~deb11u1_all.deb ...
Unpacking dnsutils (1:9.16.27-1~deb11u1) ...
Setting up liblmdb0:amd64 (0.9.24-1) ...
Setting up libicu67:amd64 (67.1-7) ...
Setting up libmaxminddb0:amd64 (1.5.2-1) ...
Setting up libfstrm0:amd64 (0.6.0-1+b1) ...
Setting up libprotobuf-c1:amd64 (1.3.3-1+b2) ...
Setting up libuv1:amd64 (1.40.0-2) ...
Setting up libmd0:amd64 (1.0.3-3) ...
Setting up libbsd0:amd64 (0.11.3-1) ...
Setting up libjson-c5:amd64 (0.15-2) ...
Setting up libxml2:amd64 (2.9.10+dfsg-6.7+deb11u2) ...
Setting up bind9-libs:amd64 (1:9.16.27-1~deb11u1) ...
Setting up libedit2:amd64 (3.1-20191231-2+b1) ...
Setting up bind9-host (1:9.16.27-1~deb11u1) ...
Setting up bind9-dnsutils (1:9.16.27-1~deb11u1) ...
Setting up dnsutils (1:9.16.27-1~deb11u1) ...
Processing triggers for libc-bin (2.31-13+deb11u3) ...
root@646845be5f23:/# dig my-apache-app
; <<>> DiG 9.16.27-Debian <<>> my-apache-app
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 52630
;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 0
;; QUESTION SECTION:
;my-apache-app. IN A
;; ANSWER SECTION:
my-apache-app. 600 IN A 172.21.0.2
;; Query time: 0 msec
;; SERVER: 127.0.0.11#53(127.0.0.11)
;; WHEN: Mon Jun 13 19:17:31 UTC 2022
;; MSG SIZE rcvd: 60
Comprobaremos el servidor DNS del contenedor:
Desde los dos contenedores se pueden resolver los dos nombres:
root@646845be5f23:/# dig contenedor1
; <<>> DiG 9.16.27-Debian <<>> contenedor1
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 3203
;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 0
;; QUESTION SECTION:
;contenedor1. IN A
;; ANSWER SECTION:
contenedor1. 600 IN A 172.21.0.3
;; Query time: 0 msec
;; SERVER: 127.0.0.11#53(127.0.0.11)
;; WHEN: Mon Jun 13 19:24:38 UTC 2022
;; MSG SIZE rcvd: 56
Conectando los contenedores a otras redes
Creamos una red bridge con direccionamiento:
atlas@olympus:~$ docker network create red2 --subnet 192.168.100.0/24 --gateway 192.168.100.1
8090d398ee4247a29a17946a161a6e7746d45c6af098b911f5b0334f56ddd32e
Creamos un contenedor conectado a red2 y comprobamos que no tiene conectividad con red1:
atlas@olympus:~$ docker run -it --name contenedor2 --network red2 debian bash
root@bd0dcf22141c:/# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
11: eth0@if12: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
link/ether 02:42:c0:a8:64:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0
inet 192.168.100.2/24 brd 192.168.100.255 scope global eth0
valid_lft forever preferred_lft forever
root@bd0dcf22141c:/# ping contenedor1
ping: contenedor1: Name or service not known
Conectamos un contenedor a una red:
atlas@olympus:~$ docker network connect red2 contenedor1
atlas@olympus:~$ docker start contenedor1
contenedor1
atlas@olympus:~$ docker start contenedor2
contenedor2
atlas@olympus:~$ docker attach contenedor1
root@4dd5cddfcc4d:/# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
13: eth0@if14: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
link/ether 02:42:ac:15:00:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0
inet 172.21.0.2/16 brd 172.21.255.255 scope global eth0
valid_lft forever preferred_lft forever
15: eth1@if16: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
link/ether 02:42:c0:a8:64:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0
inet 192.168.100.2/24 brd 192.168.100.255 scope global eth1
valid_lft forever preferred_lft forever
root@4dd5cddfcc4d:/# ping contenedor2
PING contenedor2 (192.168.100.3) 56(84) bytes of data.
64 bytes from contenedor2.red2 (192.168.100.3): icmp_seq=1 ttl=64 time=0.200 ms
64 bytes from contenedor2.red2 (192.168.100.3): icmp_seq=2 ttl=64 time=0.100 ms
^C
--- contenedor2 ping statistics ---
2 packets transmitted, 2 received, 0% packet loss, time 1001ms
rtt min/avg/max/mdev = 0.100/0.150/0.200/0.050 ms
contenedor2
tiene conectividad con contenedor1
, pero no con my-apache-app
(porque no está conectado a red2):
atlas@olympus:~$ docker attach contenedor2
root@bd0dcf22141c:/# ping contenedor1
PING contenedor1 (192.168.100.2) 56(84) bytes of data.
64 bytes from contenedor1.red2 (192.168.100.2): icmp_seq=1 ttl=64 time=0.185 ms
^C
--- contenedor1 ping statistics ---
1 packets transmitted, 1 received, 0% packet loss, time 0ms
rtt min/avg/max/mdev = 0.185/0.185/0.185/0.000 ms
root@bd0dcf22141c:/# ping my-apache-app
ping: my-apache-app: Name or service not known
Más opciones al trabajar con redes en Docker
Creo una red:
atlas@olympus:~$ docker network create --subnet 192.168.100.0/24 red3
74a6c4d6fa938121164d00f5cbfeda62ffb1b6845b1446679c275c5189a77e40
Lanzamos un contenedor en esta red:
atlas@olympus:~$ docker run -it --name contenedor --network red3 \
--ip 192.168.100.10 \
--add-host=testing.example.com:192.168.100.20 \
--dns 8.8.8.8 \
--hostname servidor1 \
debian
root@servidor1:/#
--hostname servidor1
configuró el hostname:
--ip 192.168.100.10
configuró la IP fija:
root@servidor1:/# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
28: eth0@if29: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
link/ether 02:42:c0:a8:64:0a brd ff:ff:ff:ff:ff:ff link-netnsid 0
inet 192.168.100.10/24 brd 192.168.100.255 scope global eth0
valid_lft forever preferred_lft forever
--add-host=testing.example.com:192.168.100.20
configuró un host en /etc/hosts
:
root@servidor1:/# cat /etc/hosts
127.0.0.1 localhost
::1 localhost ip6-localhost ip6-loopback
fe00::0ip6-localnet
ff00::0ip6-mcastprefix
ff02::1ip6-allnodes
ff02::2ip6-allrouters
192.168.100.20 testing.example.com
192.168.100.10 servidor1
root@servidor1:/# ping testing.example.com
PING testing.example.com (192.168.100.20) 56(84) bytes of data.
^C
--- testing.example.com ping statistics ---
3 packets transmitted, 0 received, 100% packet loss, time 2029ms
--dns 8.8.8.8
configuró el DNS:
Este DNS que vemos (que siempre se crea en las redes bridge de usuario) hará forward al que nosotros hemos configurado.
Convertir el uso de la red bridge por defecto por una definida por el usuario
Lanzamos un mongo:
atlas@olympus:~$ docker run -d --name some-mongo mongo
Unable to find image 'mongo:latest' locally
latest: Pulling from library/mongo
d7bfe07ed847: Pull complete
97ef66a8492a: Pull complete
20cec14c8f9e: Pull complete
38c3018eb09a: Pull complete
ccc9e1c2556b: Pull complete
593c62d03532: Pull complete
1a103a446c3f: Pull complete
be887b845d3f: Pull complete
e5543880b183: Pull complete
Digest: sha256:3745209b24062a8ba670878bce47ad9c944682f550044721c4abc5b4daeb863d
Status: Downloaded newer image for mongo:latest
b369ad614dad75e83e45c1bf0faff34ea286d477d4afc7b39b98f1b0199adc5e
Lanzamos un lets-chat enlazado con el mongo anterior:
atlas@olympus:~$ docker run --name some-letschat --link some-mongo:mongo -p 8080:8080 -d sdelements/lets-chat
Unable to find image 'sdelements/lets-chat:latest' locally
latest: Pulling from sdelements/lets-chat
6a5a5368e0c2: Pull complete
7b9457ec39de: Pull complete
22cf98377d30: Pull complete
01e6dd0c0aed: Pull complete
eef159360227: Pull complete
a77283727d00: Pull complete
050fb7768585: Pull complete
d2510806c35f: Pull complete
a75c55aa55f6: Pull complete
876c39157780: Pull complete
Digest: sha256:5b923d428176250653530fdac8a9f925043f30c511b77701662d7f8fab74961c
Status: Downloaded newer image for sdelements/lets-chat:latest
f078bbda16971fdf2eb830683e6c72688bb17b6cee07a00976130b419e7d7c7a
Probamos que funciona:
Usando una red bridge de usuario
Creamos la red:
atlas@olympus:~$ docker network create red_letschat
df63456e88c7d16a6bd0af594d4e8b0950f4e26c4b9870d067f7dc8f31dfd7db
Lanzamos mongo:
atlas@olympus:~$ docker run -d --network red_letschat --name mongo mongo
3583a31aa1d102886526217cb40f5bccaa088645eab416ad6ea5316dbeb7d1b5
Lanzamos lets-chat:
atlas@olympus:~$ docker run --name some-letschat --network red_letschat -p 8080:8080 -d sdelements/lets-chat
1f7157f43c7d3a60136e6908932b6fb1a6e89daf62951eed342e2d4f6dd8292e
Probamos que funciona de nuevo:
Ejemplo 1: Despliegue de la aplicación Guestbook
Creo la red:
atlas@olympus:~$ docker network create red_guestbook
0749760344c197032e1323c4add4a69912b444ab1ff6ce4a799f766d8e0db5e6
Lanzo los contenedores:
atlas@olympus:~$ docker run -d --name redis --network red_guestbook redis
Unable to find image 'redis:latest' locally
latest: Pulling from library/redis
42c077c10790: Already exists
a300d83d65f9: Pull complete
ebdc3afaab5c: Pull complete
6ce178c713e4: Pull complete
949f9d8f429f: Pull complete
4076be5e5074: Pull complete
Digest: sha256:cfda0458239615720cc16d6edf6bae7905c31265f218d2033c43cdb40cd59792
Status: Downloaded newer image for redis:latest
96cf2e1a0af36d51cb58848eec71be9bbfaeb9596531fb3bb65b376796917860
atlas@olympus:~$ docker run -d -p 80:5000 --name guestbook --network red_guestbook iesgn/guestbook
Unable to find image 'iesgn/guestbook:latest' locally
latest: Pulling from iesgn/guestbook
0ecb575e629c: Pull complete
7467d1831b69: Pull complete
feab2c490a3c: Pull complete
f15a0f46f8c3: Pull complete
937782447ff6: Pull complete
e78b7aaaab2c: Pull complete
dfce8611166c: Pull complete
3a6aeb6d9625: Pull complete
2b7e1323c92f: Pull complete
4bf029403d35: Pull complete
5e777db1f033: Pull complete
Digest: sha256:a1fc3e0652e324f643d1ebf8ab028d652aa10e13915bcc2c115d5dc9dd0ba7d2
Status: Downloaded newer image for iesgn/guestbook:latest
0d664c2abe850aefdb347c9101b07953409d9e8d33e2b879322effcea40234fe
Probamos que funciona:
Ejemplo 2: Despliegue de la aplicación Temperaturas
Creo la red:
atlas@olympus:~$ docker network create red_temperaturas
d503820887ffa9e2543930675d235f6c56b9f9fdf02524278ec62b7c04e02678
Lanzo los contenedores:
atlas@olympus:~$ docker run -d --name temperaturas-backend --network red_temperaturas iesgn/temperaturas_backend
Unable to find image 'iesgn/temperaturas_backend:latest' locally
latest: Pulling from iesgn/temperaturas_backend
0ecb575e629c: Already exists
dd4d4b42fc71: Pull complete
7ce5fbadeda7: Pull complete
54eb73ab1487: Pull complete
Digest: sha256:47bbcb85cfa1e21aecee7cf8fec4fce03197b7e0afd2229fa681116e4d8f422d
Status: Downloaded newer image for iesgn/temperaturas_backend:latest
ef1fbd2d31ac6c031f6bdb374983d6f7552ea8f591d4d062c57fb6ac4be43e5b
atlas@olympus:~$ docker run -d -p 80:3000 --name temperaturas-frontend --network red_temperaturas iesgn/temperaturas_frontend
Unable to find image 'iesgn/temperaturas_frontend:latest' locally
latest: Pulling from iesgn/temperaturas_frontend
0ecb575e629c: Already exists
1b0ea791d129: Pull complete
18ffb3e704a1: Pull complete
d724eea63276: Pull complete
Digest: sha256:7a2b7b66f830e0905d2b0b7faf33a5bea3da7c12c8ea75abdc034603307c7677
Status: Downloaded newer image for iesgn/temperaturas_frontend:latest
8ffd4cf58fa19fb7f39ed690b7a724b0c2e364e66bba1359ae3ba5212e48f4ae
Probamos que funciona:
Ejemplo 3: Despliegue de Wordpress + MariaDB
Creo la red:
atlas@olympus:~$ docker network create red_wp
80c955b07b17dcf9eda18567b0b65cba6344bf3ac45beba35eff131e77630abf
Lanzo los contenedores:
atlas@olympus:~$ docker run -d --name servidor_mysql \
--network red_wp \
-v /opt/mysql_wp:/var/lib/mysql \
-e MYSQL_DATABASE=bd_wp \
-e MYSQL_USER=user_wp \
-e MYSQL_PASSWORD=asdasd \
-e MYSQL_ROOT_PASSWORD=asdasd \
mariadb
3d892aa3847a19b4fc877dfa2dd085e7182d07f01ccc9be42fd6aa731e20255e
atlas@olympus:~$ docker run -d --name servidor_wp \
--network red_wp \
-v /opt/wordpress:/var/www/html/wp-content \
-e WORDPRESS_DB_HOST=servidor_mysql \
-e WORDPRESS_DB_USER=user_wp \
-e WORDPRESS_DB_PASSWORD=asdasd \
-e WORDPRESS_DB_NAME=bd_wp \
-p 80:80 \
wordpress
Unable to find image 'wordpress:latest' locally
latest: Pulling from library/wordpress
42c077c10790: Already exists
8934009a9160: Already exists
5357ac116991: Already exists
54ae63894b5a: Already exists
772088206f85: Already exists
3b81c5474649: Already exists
c62a528527ae: Already exists
344c792709d4: Already exists
ef9638273c35: Already exists
4ec70638e42f: Already exists
5a0f65f5bb3b: Already exists
55578a5ce5e8: Already exists
f1dd85b4dfa5: Already exists
35dc259d9d51: Pull complete
48147606c534: Pull complete
c88c969d9899: Pull complete
e08b6500594a: Pull complete
027690aff84d: Pull complete
8770aef363f4: Pull complete
336e4cd7d982: Pull complete
8e0e84b1add6: Pull complete
Digest: sha256:92a0f6f7e92eab575659ff6c6ee3d1abb56752977d1d729de5da1a876f9f1f42
Status: Downloaded newer image for wordpress:latest
ec1b9fac1479fde88682d5071b86f198b69a9442064b29bc3ac5770ed1a07b33
Muestro que están activos:
atlas@olympus:~$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
ec1b9fac1479 wordpress "docker-entrypoint.s…" 57 seconds ago Up 55 seconds 0.0.0.0:80->80/tcp servidor_wp
3d892aa3847a mariadb "docker-entrypoint.s…" 2 minutes ago Up 2 minutes 3306/tcp servidor_mysql
Probamos que funciona (haré la instalación y lo mostraré directamente funcionando):
Ejemplo 4: Despliegue de Tomcat + Nginx
Creo la red:
atlas@olympus:~$ docker network create red_tomcat
891d29f1d2054410e0c43654924fe8400584ea1d2b411262a9d4085182e60234
Creo el directorio tomcat y entro:
Descargo en él los 2 ficheros que necesito y muestro que los tengo:
atlas@olympus:~/tomcat$ wget https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion4/ejemplo4/default.conf
--2022-06-14 20:35:44-- https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion4/ejemplo4/default.conf
Resolving raw.githubusercontent.com (raw.githubusercontent.com)... 185.199.108.133, 185.199.111.133, 185.199.109.133, ...
Connecting to raw.githubusercontent.com (raw.githubusercontent.com)|185.199.108.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 387 [text/plain]
Saving to: ‘default.conf’
default.conf 100%[=========================================================================================>] 387 --.-KB/s in 0s
2022-06-14 20:35:44 (15.6 MB/s) - ‘default.conf’ saved [387/387]
atlas@olympus:~/tomcat$ wget https://github.com/iesgn/curso_docker_2021/raw/main/ejemplos/sesion4/ejemplo4/sample.war
--2022-06-14 20:38:59-- https://github.com/iesgn/curso_docker_2021/raw/main/ejemplos/sesion4/ejemplo4/sample.war
Resolving github.com (github.com)... 140.82.121.4
Connecting to github.com (github.com)|140.82.121.4|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion4/ejemplo4/sample.war [following]
--2022-06-14 20:38:59-- https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion4/ejemplo4/sample.war
Resolving raw.githubusercontent.com (raw.githubusercontent.com)... 185.199.111.133, 185.199.108.133, 185.199.109.133, ...
Connecting to raw.githubusercontent.com (raw.githubusercontent.com)|185.199.111.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 4606 (4.5K) [application/octet-stream]
Saving to: ‘sample.war’
sample.war 100%[=========================================================================================>] 4.50K --.-KB/s in 0.002s
2022-06-14 20:38:59 (2.21 MB/s) - ‘sample.war’ saved [4606/4606]
atlas@olympus:~/tomcat$ ls -la
total 20
drwxr-xr-x 2 atlas atlas 4096 Jun 14 20:38 .
drwxr-xr-x 42 atlas atlas 4096 Jun 14 20:32 ..
-rw-r--r-- 1 atlas atlas 387 Jun 14 20:35 default.conf
-rw-r--r-- 1 atlas atlas 4606 Jun 14 20:38 sample.war
Lanzo el contenedor de Tomcat:
atlas@olympus:~/tomcat$ docker run -d --name aplicacionjava \
--network red_tomcat \
-v /home/atlas/tomcat/sample.war:/usr/local/tomcat/webapps/sample.war:ro \
tomcat:9.0
Unable to find image 'tomcat:9.0' locally
9.0: Pulling from library/tomcat
e756f3fdd6a3: Already exists
bf168a674899: Pull complete
e604223835cc: Pull complete
6d5c91c4cd86: Pull complete
5e20d165240e: Pull complete
1334d60df9a8: Pull complete
16c2728dcd90: Pull complete
05288798d23d: Pull complete
3bbce73846a1: Pull complete
58e753cca0c7: Pull complete
Digest: sha256:8558e9b51d8aa9f08d6611c54a832b1be64636e713532729fca44774d6a0765d
Status: Downloaded newer image for tomcat:9.0
bd9c22e54e6e7b96e27ab502c0db185ca24ea87635d222c8e16aed84e92dc6c6
Lanzo el contenedor de Nginx:
atlas@olympus:~/tomcat$ docker run -d --name proxy \
-p 80:80 \
--network red_tomcat \
-v /home/atlas/tomcat/default.conf:/etc/nginx/conf.d/default.conf:ro \
nginx
a62ecf82ea16924e06a49bbedd7a32857a2ebebb04becde4b0e57ed8d4f31751
Probamos que funciona:
Ejercicios redes
Creo red1
:
atlas@olympus:~$ docker network create red1 --subnet 172.28.0.0/16 --gateway 172.28.0.1
83eb74c0d72db336bd40fd2c48cdd6583b8b232b304ecc858fde6e5d05432709
Creo red2
:
atlas@olympus:~$ docker network create red2
501db55f3c489ba353ac40105eea56c5053707f04199af73dc47b38f317e677d
Lanzo el primer contenedor e instalo ping:
atlas@olympus:~$ docker run -it --name u1 --network red1 --ip 172.28.0.10 --hostname host1 ubuntu:20.04
root@host1:/# apt update
Get:1 http://security.ubuntu.com/ubuntu focal-security InRelease [114 kB]
Get:2 http://archive.ubuntu.com/ubuntu focal InRelease [265 kB]
Get:3 http://archive.ubuntu.com/ubuntu focal-updates InRelease [114 kB]
Get:4 http://security.ubuntu.com/ubuntu focal-security/multiverse amd64 Packages [27.5 kB]
Get:5 http://archive.ubuntu.com/ubuntu focal-backports InRelease [108 kB]
Get:6 http://security.ubuntu.com/ubuntu focal-security/universe amd64 Packages [880 kB]
Get:7 http://security.ubuntu.com/ubuntu focal-security/main amd64 Packages [1931 kB]
Get:8 http://archive.ubuntu.com/ubuntu focal/main amd64 Packages [1275 kB]
Get:9 http://archive.ubuntu.com/ubuntu focal/universe amd64 Packages [11.3 MB]
Get:10 http://security.ubuntu.com/ubuntu focal-security/restricted amd64 Packages [1286 kB]
Get:11 http://archive.ubuntu.com/ubuntu focal/restricted amd64 Packages [33.4 kB]
Get:12 http://archive.ubuntu.com/ubuntu focal/multiverse amd64 Packages [177 kB]
Get:13 http://archive.ubuntu.com/ubuntu focal-updates/main amd64 Packages [2364 kB]
Get:14 http://archive.ubuntu.com/ubuntu focal-updates/restricted amd64 Packages [1365 kB]
Get:15 http://archive.ubuntu.com/ubuntu focal-updates/universe amd64 Packages [1169 kB]
Get:16 http://archive.ubuntu.com/ubuntu focal-updates/multiverse amd64 Packages [30.2 kB]
Get:17 http://archive.ubuntu.com/ubuntu focal-backports/universe amd64 Packages [27.1 kB]
Get:18 http://archive.ubuntu.com/ubuntu focal-backports/main amd64 Packages [53.8 kB]
Fetched 22.6 MB in 9s (2566 kB/s)
Reading package lists... Done
Building dependency tree
Reading state information... Done
7 packages can be upgraded. Run 'apt list --upgradable' to see them.
root@host1:/# apt install inetutils-ping
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following additional packages will be installed:
libidn11 netbase
The following NEW packages will be installed:
inetutils-ping libidn11 netbase
0 upgraded, 3 newly installed, 0 to remove and 7 not upgraded.
Need to get 120 kB of archives.
After this operation, 657 kB of additional disk space will be used.
Do you want to continue? [Y/n] y
Get:1 http://archive.ubuntu.com/ubuntu focal/main amd64 netbase all 6.1 [13.1 kB]
Get:2 http://archive.ubuntu.com/ubuntu focal/main amd64 libidn11 amd64 1.33-2.2ubuntu2 [46.2 kB]
Get:3 http://archive.ubuntu.com/ubuntu focal-updates/universe amd64 inetutils-ping amd64 2:1.9.4-11ubuntu0.1 [60.7 kB]
Fetched 120 kB in 1s (113 kB/s)
debconf: delaying package configuration, since apt-utils is not installed
Selecting previously unselected package netbase.
(Reading database ... 4126 files and directories currently installed.)
Preparing to unpack .../archives/netbase_6.1_all.deb ...
Unpacking netbase (6.1) ...
Selecting previously unselected package libidn11:amd64.
Preparing to unpack .../libidn11_1.33-2.2ubuntu2_amd64.deb ...
Unpacking libidn11:amd64 (1.33-2.2ubuntu2) ...
Selecting previously unselected package inetutils-ping.
Preparing to unpack .../inetutils-ping_2%3a1.9.4-11ubuntu0.1_amd64.deb ...
Unpacking inetutils-ping (2:1.9.4-11ubuntu0.1) ...
Setting up libidn11:amd64 (1.33-2.2ubuntu2) ...
Setting up netbase (6.1) ...
Setting up inetutils-ping (2:1.9.4-11ubuntu0.1) ...
Processing triggers for libc-bin (2.31-0ubuntu9.9) ...
Mostrar la configuración de red de u1
:
Lanzo el segundo contenedor e instalo ping:
atlas@olympus:~$ docker run -it --name u2 --network red2 --hostname host2 ubuntu:20.04
root@host2:/# apt update
Get:1 http://archive.ubuntu.com/ubuntu focal InRelease [265 kB]
Get:2 http://security.ubuntu.com/ubuntu focal-security InRelease [114 kB]
Get:3 http://archive.ubuntu.com/ubuntu focal-updates InRelease [114 kB]
Get:4 http://archive.ubuntu.com/ubuntu focal-backports InRelease [108 kB]
Get:5 http://archive.ubuntu.com/ubuntu focal/multiverse amd64 Packages [177 kB]
Get:6 http://archive.ubuntu.com/ubuntu focal/main amd64 Packages [1275 kB]
Get:7 http://security.ubuntu.com/ubuntu focal-security/universe amd64 Packages [880 kB]
Get:8 http://archive.ubuntu.com/ubuntu focal/restricted amd64 Packages [33.4 kB]
Get:9 http://archive.ubuntu.com/ubuntu focal/universe amd64 Packages [11.3 MB]
Get:10 http://security.ubuntu.com/ubuntu focal-security/main amd64 Packages [1931 kB]
Get:11 http://security.ubuntu.com/ubuntu focal-security/multiverse amd64 Packages [27.5 kB]
Get:12 http://security.ubuntu.com/ubuntu focal-security/restricted amd64 Packages [1286 kB]
Get:13 http://archive.ubuntu.com/ubuntu focal-updates/universe amd64 Packages [1169 kB]
Get:14 http://archive.ubuntu.com/ubuntu focal-updates/restricted amd64 Packages [1365 kB]
Get:15 http://archive.ubuntu.com/ubuntu focal-updates/main amd64 Packages [2364 kB]
Get:16 http://archive.ubuntu.com/ubuntu focal-updates/multiverse amd64 Packages [30.2 kB]
Get:17 http://archive.ubuntu.com/ubuntu focal-backports/main amd64 Packages [53.8 kB]
Get:18 http://archive.ubuntu.com/ubuntu focal-backports/universe amd64 Packages [27.1 kB]
Fetched 22.6 MB in 25s (905 kB/s)
Reading package lists... Done
Building dependency tree
Reading state information... Done
7 packages can be upgraded. Run 'apt list --upgradable' to see them.
root@host2:/# apt install inetutils-ping
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following additional packages will be installed:
libidn11 netbase
The following NEW packages will be installed:
inetutils-ping libidn11 netbase
0 upgraded, 3 newly installed, 0 to remove and 7 not upgraded.
Need to get 120 kB of archives.
After this operation, 657 kB of additional disk space will be used.
Do you want to continue? [Y/n] y
Get:1 http://archive.ubuntu.com/ubuntu focal/main amd64 netbase all 6.1 [13.1 kB]
Get:2 http://archive.ubuntu.com/ubuntu focal/main amd64 libidn11 amd64 1.33-2.2ubuntu2 [46.2 kB]
Get:3 http://archive.ubuntu.com/ubuntu focal-updates/universe amd64 inetutils-ping amd64 2:1.9.4-11ubuntu0.1 [60.7 kB]
Fetched 120 kB in 0s (3242 kB/s)
debconf: delaying package configuration, since apt-utils is not installed
Selecting previously unselected package netbase.
(Reading database ... 4126 files and directories currently installed.)
Preparing to unpack .../archives/netbase_6.1_all.deb ...
Unpacking netbase (6.1) ...
Selecting previously unselected package libidn11:amd64.
Preparing to unpack .../libidn11_1.33-2.2ubuntu2_amd64.deb ...
Unpacking libidn11:amd64 (1.33-2.2ubuntu2) ...
Selecting previously unselected package inetutils-ping.
Preparing to unpack .../inetutils-ping_2%3a1.9.4-11ubuntu0.1_amd64.deb ...
Unpacking inetutils-ping (2:1.9.4-11ubuntu0.1) ...
Setting up libidn11:amd64 (1.33-2.2ubuntu2) ...
Setting up netbase (6.1) ...
Setting up inetutils-ping (2:1.9.4-11ubuntu0.1) ...
Processing triggers for libc-bin (2.31-0ubuntu9.9) ...
Mostrar la configuración de red de u2
:
Compruebo que el ping IP u1
→ u2
no funciona:
Compruebo que el ping por nombre u1
→ u2
no funciona:
Compruebo que el ping IP u2
→ u1
no funciona:
Compruebo que el ping por nombre u2
→ u1
no funciona:
Conectamos ahora u1
a red2
:
Comprobamos que ahora el ping IP/nombre u1
→ u2
funciona:
Escenarios multicontenedor
Instalación de docker-compose
El fichero docker-compose.yml
docker-compose
se ejecuta en el mismo directorio donde esté el docker-compose.yml
, por lo que acabaremos teniendo un directorio por cada docker-compose.yml
.
Por ejemplo, para Let’s Chat
, podríamos tener este docker-compose.yml
dentro de un directorio:
version: '3.1'
services:
app:
container_name: letschat
image: sdelements/lets-chat
restart: always
environment:
LCB_DATABASE_URI: mongodb://mongo/letschat
ports:
- 80:8080
depends_on:
- db
db:
container_name: mongo
image: mongo
restart: always
volumes:
- /opt/mongo:/data/db
Cada service
crea un contenedor.
depends_on
obliga a que X contenedor no se inicie hasta que otro esté iniciado.
Por cada escenario docker-compose
se crea un bridge de usuario. Existirá resolución DNS para nombre de contenedor y de servicio.
El comando docker-compose
Creo la estructura de directorios /home/atlas/docker/letschat
con el siguiente docker-compose.yml
dentro:
version: '3.1'
services:
app:
container_name: letschat
image: sdelements/lets-chat
restart: always
environment:
LCB_DATABASE_URI: mongodb://mongo/letschat
ports:
- 80:8080
depends_on:
- db
db:
container_name: mongo
image: mongo
restart: always
volumes:
- /opt/mongo:/data/db
Lanzo el escenario:
atlas@olympus:~/docker/letschat$ docker-compose up -d
Creating mongo ... done
Creating letschat ... done
Comprobamos que los contenedores se están ejecutando:
atlas@olympus:~/docker/letschat$ docker-compose ps
Name Command State Ports
-------------------------------------------------------------------------------
letschat npm start Up 5222/tcp, 0.0.0.0:80->8080/tcp
mongo docker-entrypoint.sh mongod Up 27017/tcp
Comprobamos que funciona:
Para eliminar el escenario:
atlas@olympus:~/docker/letschat$ docker-compose down
Stopping letschat ... done
Stopping mongo ... done
Removing letschat ... done
Removing mongo ... done
Removing network letschat_default
Almacenamiento con docker-compose
Volúmenes docker-compose
Ejemplo:
version: '3.1'
services:
db:
container_name: contenedor_mariadb
image: mariadb
restart: always
environment:
MYSQL_ROOT_PASSWORD: asdasd
volumes:
- mariadb_data:/var/lib/mysql
volumes:
mariadb_data:
Lanzo el escenario:
atlas@olympus:~/docker/volumenes$ docker-compose up -d
Creating network "volumenes_default" with the default driver
Creating volume "volumenes_mariadb_data" with default driver
Creating contenedor_mariadb ... done
Compruebo que está activo:
atlas@olympus:~/docker/volumenes$ docker-compose ps
Name Command State Ports
---------------------------------------------------------------------
contenedor_mariadb docker-entrypoint.sh mariadbd Up 3306/tcp
Compruebo que se ha creado el volumen:
atlas@olympus:~/docker/volumenes$ docker volume ls
DRIVER VOLUME NAME
local 3f39653a3a30f881672c01433725daeb04ab6ba632a723b1af18b093f50e06ae
local 04e463e496d920db4b021cd270aa770d27abaaf32a08d0d035d1fe03356f87b3
local 7df3bfbe82aaf633a16cafb30628c3d0384d48404851b99dc892cb337d530950
local 7e6492fdc4515b59e4d3e86d9c69f31b6e771d78e3c8231dbb0a3eed24bed33c
local 07c295fb652fc3ec7f0f51a3df2d13849aac8795b44e4b55e22e371dea84022d
local 19b03e7f9608f78aac80ee1284c4fa4c5f78afb723499cc664f7753971639753
local 65eb5fc7fc9f541f1dd35effc2e456e615f6ef51670ef07a9971d2278c9dd4ee
local 76c389c617b86588b5950575e9bfbb3f9a17316c491880f30621d3e3bcbe251f
local 256e88e1d29e428176b13909592ca4f124845226dec90aae73f9ddfd26021c9c
local 582b8ad89272ee7607a9e56dfaeae28c1eba9a7263a8052d64e82e6361b4ef1c
local 972306d6e9955703c733bd57d9e270d953e8a028760fd6d3af13c2085af8d1f8
local d13dcfcda6c5bcbb2b75fdce9f7b74136b88d82d8d4c2e08e6b957840273b0b4
local da9451ceb333f905d8a8fbe4e764ab2a057139f1641a024ffae408b81cfb72d7
local datos_compartidos
local e6c217e966db3c2491c2b6989789f6c7488aaa1222313415722e3d06aaedca03
local f108fc0c5812145adaa6d4987a0afd9748876ff8bd7b5520e916eb530a3d35c3
local f9783771ca7c6480508aab09a722d746803e0955cd6b0e8cadcebfd7f1aff44a
local nextcloud
local volumen_web
local volumenes_mariadb_data
local wwwroot
Compruebo que el montaje del volumen se ha realizado en el contenedor:
"Mounts": [
{
"Type": "volume",
"Name": "volumenes_mariadb_data",
"Source": "/var/lib/docker/volumes/volumenes_mariadb_data/_data",
"Destination": "/var/lib/mysql",
"Driver": "local",
"Mode": "rw",
"RW": true,
"Propagation": ""
}
],
Elimino escenario + posibles volúmenes:
atlas@olympus:~/docker/volumenes$ docker-compose down -v
Stopping contenedor_mariadb ... done
Removing contenedor_mariadb ... done
Removing network volumenes_default
Removing volume volumenes_mariadb_data
Bind mount docker-compose
Ejemplo:
version: '3.1'
services:
db:
container_name: contenedor_mariadb
image: mariadb
restart: always
environment:
MYSQL_ROOT_PASSWORD: asdasd
volumes:
- ./data:/var/lib/mysql
Lanzo el escenario
atlas@olympus:~/docker/bindmount$ docker-compose up -d
Creating network "bindmount_default" with the default driver
Creating contenedor_mariadb ... done
Compruebo que se ha creado el directorio data
:
atlas@olympus:~/docker/bindmount$ cd data
atlas@olympus:~/docker/bindmount/data$ ls -la
total 139260
drwxr-xr-x 5 systemd-coredump systemd-coredump 4096 Jun 15 21:57 .
drwxr-xr-x 3 atlas atlas 4096 Jun 15 21:57 ..
-rw-rw---- 1 systemd-coredump systemd-coredump 16719872 Jun 15 21:57 aria_log.00000001
-rw-rw---- 1 systemd-coredump systemd-coredump 52 Jun 15 21:57 aria_log_control
-rw-rw---- 1 systemd-coredump systemd-coredump 9 Jun 15 21:57 ddl_recovery.log
-rw-rw---- 1 systemd-coredump systemd-coredump 868 Jun 15 21:57 ib_buffer_pool
-rw-rw---- 1 systemd-coredump systemd-coredump 12582912 Jun 15 21:57 ibdata1
-rw-rw---- 1 systemd-coredump systemd-coredump 100663296 Jun 15 21:57 ib_logfile0
-rw-rw---- 1 systemd-coredump systemd-coredump 12582912 Jun 15 21:57 ibtmp1
-rw-rw---- 1 systemd-coredump systemd-coredump 0 Jun 15 21:57 multi-master.info
drwx------ 2 systemd-coredump systemd-coredump 4096 Jun 15 21:57 mysql
-rw-r--r-- 1 systemd-coredump systemd-coredump 14 Jun 15 21:57 mysql_upgrade_info
drwx------ 2 systemd-coredump systemd-coredump 4096 Jun 15 21:57 performance_schema
drwx------ 2 systemd-coredump systemd-coredump 12288 Jun 15 21:57 sys
Redes con docker-compose
Ejemplo:
version: '3.1'
services:
app:
container_name: servidor_web
image: httpd:2.4
restart: always
ports:
- 8080:80
networks:
red_web:
ipv4_address: 192.168.10.10
red_interna:
ipv4_address: 192.168.20.10
hostname: servidor_web
db:
container_name: servidor_mariadb
image: mariadb
environment:
MYSQL_ROOT_PASSWORD: asdasd
restart: always
networks:
red_interna:
ipv4_address: 192.168.20.20
hostname: servidor_mariadb
networks:
red_web:
ipam:
config:
- subnet: 192.168.10.0/24
red_interna:
ipam:
config:
- subnet: 192.168.20.0/24
Lanzo el escenario:
atlas@olympus:~/docker/redes$ docker-compose up -d
Creating network "redes_red_web" with the default driver
Creating network "redes_red_interna" with the default driver
Creating servidor_web ... done
Creating servidor_mariadb ... done
Compruebo que los contenedores se están ejecutando:
atlas@olympus:~/docker/redes$ docker-compose ps
Name Command State Ports
-------------------------------------------------------------------------------
servidor_mariadb docker-entrypoint.sh mariadbd Up 3306/tcp
servidor_web httpd-foreground Up 0.0.0.0:8080->80/tcp
Accedo a servidor_web
e instalo paquetes para comprobaciones:
atlas@olympus:~/docker/redes$ docker-compose exec app bash
root@servidor_web:/usr/local/apache2# apt-get update && apt-get install -y inetutils-ping iproute2 dnsutils
Get:1 http://deb.debian.org/debian bullseye InRelease [116 kB]
Get:2 http://security.debian.org/debian-security bullseye-security InRelease [44.1 kB]
Get:3 http://deb.debian.org/debian bullseye-updates InRelease [39.4 kB]
Get:4 http://deb.debian.org/debian bullseye/main amd64 Packages [8182 kB]
Get:5 http://security.debian.org/debian-security bullseye-security/main amd64 Packages [154 kB]
Get:6 http://deb.debian.org/debian bullseye-updates/main amd64 Packages [2592 B]
Fetched 8539 kB in 4s (2245 kB/s)
Reading package lists... Done
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
The following additional packages will be installed:
bind9-dnsutils bind9-host bind9-libs libatm1 libbpf0 libbsd0 libcap2 libcap2-bin libedit2 libelf1 libfstrm0 libjson-c5 liblmdb0 libmaxminddb0 libmd0 libmnl0 libpam-cap
libprotobuf-c1 libuv1 libxtables12 netbase
Suggested packages:
iproute2-doc mmdb-bin
The following NEW packages will be installed:
bind9-dnsutils bind9-host bind9-libs dnsutils inetutils-ping iproute2 libatm1 libbpf0 libbsd0 libcap2 libcap2-bin libedit2 libelf1 libfstrm0 libjson-c5 liblmdb0
libmaxminddb0 libmd0 libmnl0 libpam-cap libprotobuf-c1 libuv1 libxtables12 netbase
0 upgraded, 24 newly installed, 0 to remove and 1 not upgraded.
Need to get 4565 kB of archives.
After this operation, 11.6 MB of additional disk space will be used.
Get:1 http://deb.debian.org/debian bullseye/main amd64 libelf1 amd64 0.183-1 [165 kB]
Get:2 http://deb.debian.org/debian bullseye/main amd64 libbpf0 amd64 1:0.3-2 [98.3 kB]
Get:3 http://deb.debian.org/debian bullseye/main amd64 libmd0 amd64 1.0.3-3 [28.0 kB]
Get:4 http://deb.debian.org/debian bullseye/main amd64 libbsd0 amd64 0.11.3-1 [108 kB]
Get:5 http://deb.debian.org/debian bullseye/main amd64 libcap2 amd64 1:2.44-1 [23.6 kB]
Get:6 http://deb.debian.org/debian bullseye/main amd64 libmnl0 amd64 1.0.4-3 [12.5 kB]
Get:7 http://deb.debian.org/debian bullseye/main amd64 libxtables12 amd64 1.8.7-1 [45.1 kB]
Get:8 http://deb.debian.org/debian bullseye/main amd64 libcap2-bin amd64 1:2.44-1 [32.6 kB]
Get:9 http://deb.debian.org/debian bullseye/main amd64 iproute2 amd64 5.10.0-4 [930 kB]
Get:10 http://deb.debian.org/debian bullseye/main amd64 netbase all 6.3 [19.9 kB]
Get:11 http://deb.debian.org/debian bullseye/main amd64 libfstrm0 amd64 0.6.0-1+b1 [21.5 kB]
Get:12 http://deb.debian.org/debian bullseye/main amd64 libjson-c5 amd64 0.15-2 [42.8 kB]
Get:13 http://deb.debian.org/debian bullseye/main amd64 liblmdb0 amd64 0.9.24-1 [45.0 kB]
Get:14 http://deb.debian.org/debian bullseye/main amd64 libmaxminddb0 amd64 1.5.2-1 [29.8 kB]
Get:15 http://deb.debian.org/debian bullseye/main amd64 libprotobuf-c1 amd64 1.3.3-1+b2 [27.0 kB]
Get:16 http://deb.debian.org/debian bullseye/main amd64 libuv1 amd64 1.40.0-2 [132 kB]
Get:17 http://deb.debian.org/debian bullseye/main amd64 bind9-libs amd64 1:9.16.27-1~deb11u1 [1413 kB]
Get:18 http://deb.debian.org/debian bullseye/main amd64 bind9-host amd64 1:9.16.27-1~deb11u1 [302 kB]
Get:19 http://deb.debian.org/debian bullseye/main amd64 libedit2 amd64 3.1-20191231-2+b1 [96.7 kB]
Get:20 http://deb.debian.org/debian bullseye/main amd64 bind9-dnsutils amd64 1:9.16.27-1~deb11u1 [398 kB]
Get:21 http://deb.debian.org/debian bullseye/main amd64 dnsutils all 1:9.16.27-1~deb11u1 [262 kB]
Get:22 http://deb.debian.org/debian bullseye/main amd64 inetutils-ping amd64 2:2.0-1 [245 kB]
Get:23 http://deb.debian.org/debian bullseye/main amd64 libatm1 amd64 1:2.5.1-4 [71.3 kB]
Get:24 http://deb.debian.org/debian bullseye/main amd64 libpam-cap amd64 1:2.44-1 [15.4 kB]
Fetched 4565 kB in 2s (2995 kB/s)
debconf: delaying package configuration, since apt-utils is not installed
Selecting previously unselected package libelf1:amd64.
(Reading database ... 6833 files and directories currently installed.)
Preparing to unpack .../00-libelf1_0.183-1_amd64.deb ...
Unpacking libelf1:amd64 (0.183-1) ...
Selecting previously unselected package libbpf0:amd64.
Preparing to unpack .../01-libbpf0_1%3a0.3-2_amd64.deb ...
Unpacking libbpf0:amd64 (1:0.3-2) ...
Selecting previously unselected package libmd0:amd64.
Preparing to unpack .../02-libmd0_1.0.3-3_amd64.deb ...
Unpacking libmd0:amd64 (1.0.3-3) ...
Selecting previously unselected package libbsd0:amd64.
Preparing to unpack .../03-libbsd0_0.11.3-1_amd64.deb ...
Unpacking libbsd0:amd64 (0.11.3-1) ...
Selecting previously unselected package libcap2:amd64.
Preparing to unpack .../04-libcap2_1%3a2.44-1_amd64.deb ...
Unpacking libcap2:amd64 (1:2.44-1) ...
Selecting previously unselected package libmnl0:amd64.
Preparing to unpack .../05-libmnl0_1.0.4-3_amd64.deb ...
Unpacking libmnl0:amd64 (1.0.4-3) ...
Selecting previously unselected package libxtables12:amd64.
Preparing to unpack .../06-libxtables12_1.8.7-1_amd64.deb ...
Unpacking libxtables12:amd64 (1.8.7-1) ...
Selecting previously unselected package libcap2-bin.
Preparing to unpack .../07-libcap2-bin_1%3a2.44-1_amd64.deb ...
Unpacking libcap2-bin (1:2.44-1) ...
Selecting previously unselected package iproute2.
Preparing to unpack .../08-iproute2_5.10.0-4_amd64.deb ...
Unpacking iproute2 (5.10.0-4) ...
Selecting previously unselected package netbase.
Preparing to unpack .../09-netbase_6.3_all.deb ...
Unpacking netbase (6.3) ...
Selecting previously unselected package libfstrm0:amd64.
Preparing to unpack .../10-libfstrm0_0.6.0-1+b1_amd64.deb ...
Unpacking libfstrm0:amd64 (0.6.0-1+b1) ...
Selecting previously unselected package libjson-c5:amd64.
Preparing to unpack .../11-libjson-c5_0.15-2_amd64.deb ...
Unpacking libjson-c5:amd64 (0.15-2) ...
Selecting previously unselected package liblmdb0:amd64.
Preparing to unpack .../12-liblmdb0_0.9.24-1_amd64.deb ...
Unpacking liblmdb0:amd64 (0.9.24-1) ...
Selecting previously unselected package libmaxminddb0:amd64.
Preparing to unpack .../13-libmaxminddb0_1.5.2-1_amd64.deb ...
Unpacking libmaxminddb0:amd64 (1.5.2-1) ...
Selecting previously unselected package libprotobuf-c1:amd64.
Preparing to unpack .../14-libprotobuf-c1_1.3.3-1+b2_amd64.deb ...
Unpacking libprotobuf-c1:amd64 (1.3.3-1+b2) ...
Selecting previously unselected package libuv1:amd64.
Preparing to unpack .../15-libuv1_1.40.0-2_amd64.deb ...
Unpacking libuv1:amd64 (1.40.0-2) ...
Selecting previously unselected package bind9-libs:amd64.
Preparing to unpack .../16-bind9-libs_1%3a9.16.27-1~deb11u1_amd64.deb ...
Unpacking bind9-libs:amd64 (1:9.16.27-1~deb11u1) ...
Selecting previously unselected package bind9-host.
Preparing to unpack .../17-bind9-host_1%3a9.16.27-1~deb11u1_amd64.deb ...
Unpacking bind9-host (1:9.16.27-1~deb11u1) ...
Selecting previously unselected package libedit2:amd64.
Preparing to unpack .../18-libedit2_3.1-20191231-2+b1_amd64.deb ...
Unpacking libedit2:amd64 (3.1-20191231-2+b1) ...
Selecting previously unselected package bind9-dnsutils.
Preparing to unpack .../19-bind9-dnsutils_1%3a9.16.27-1~deb11u1_amd64.deb ...
Unpacking bind9-dnsutils (1:9.16.27-1~deb11u1) ...
Selecting previously unselected package dnsutils.
Preparing to unpack .../20-dnsutils_1%3a9.16.27-1~deb11u1_all.deb ...
Unpacking dnsutils (1:9.16.27-1~deb11u1) ...
Selecting previously unselected package inetutils-ping.
Preparing to unpack .../21-inetutils-ping_2%3a2.0-1_amd64.deb ...
Unpacking inetutils-ping (2:2.0-1) ...
Selecting previously unselected package libatm1:amd64.
Preparing to unpack .../22-libatm1_1%3a2.5.1-4_amd64.deb ...
Unpacking libatm1:amd64 (1:2.5.1-4) ...
Selecting previously unselected package libpam-cap:amd64.
Preparing to unpack .../23-libpam-cap_1%3a2.44-1_amd64.deb ...
Unpacking libpam-cap:amd64 (1:2.44-1) ...
Setting up liblmdb0:amd64 (0.9.24-1) ...
Setting up libmaxminddb0:amd64 (1.5.2-1) ...
Setting up libfstrm0:amd64 (0.6.0-1+b1) ...
Setting up libatm1:amd64 (1:2.5.1-4) ...
Setting up libprotobuf-c1:amd64 (1.3.3-1+b2) ...
Setting up libcap2:amd64 (1:2.44-1) ...
Setting up libcap2-bin (1:2.44-1) ...
Setting up libuv1:amd64 (1.40.0-2) ...
Setting up libmnl0:amd64 (1.0.4-3) ...
Setting up libxtables12:amd64 (1.8.7-1) ...
Setting up libmd0:amd64 (1.0.3-3) ...
Setting up netbase (6.3) ...
Setting up libbsd0:amd64 (0.11.3-1) ...
Setting up libelf1:amd64 (0.183-1) ...
Setting up libpam-cap:amd64 (1:2.44-1) ...
debconf: unable to initialize frontend: Dialog
debconf: (No usable dialog-like program is installed, so the dialog based frontend cannot be used. at /usr/share/perl5/Debconf/FrontEnd/Dialog.pm line 78.)
debconf: falling back to frontend: Readline
debconf: unable to initialize frontend: Readline
debconf: (Can't locate Term/ReadLine.pm in @INC (you may need to install the Term::ReadLine module) (@INC contains: /etc/perl /usr/local/lib/x86_64-linux-gnu/perl/5.32.1 /usr/local/share/perl/5.32.1 /usr/lib/x86_64-linux-gnu/perl5/5.32 /usr/share/perl5 /usr/lib/x86_64-linux-gnu/perl-base /usr/lib/x86_64-linux-gnu/perl/5.32 /usr/share/perl/5.32 /usr/local/lib/site_perl) at /usr/share/perl5/Debconf/FrontEnd/Readline.pm line 7.)
debconf: falling back to frontend: Teletype
Setting up libjson-c5:amd64 (0.15-2) ...
Setting up bind9-libs:amd64 (1:9.16.27-1~deb11u1) ...
Setting up libedit2:amd64 (3.1-20191231-2+b1) ...
Setting up inetutils-ping (2:2.0-1) ...
Setting up libbpf0:amd64 (1:0.3-2) ...
Setting up bind9-host (1:9.16.27-1~deb11u1) ...
Setting up iproute2 (5.10.0-4) ...
debconf: unable to initialize frontend: Dialog
debconf: (No usable dialog-like program is installed, so the dialog based frontend cannot be used. at /usr/share/perl5/Debconf/FrontEnd/Dialog.pm line 78.)
debconf: falling back to frontend: Readline
debconf: unable to initialize frontend: Readline
debconf: (Can't locate Term/ReadLine.pm in @INC (you may need to install the Term::ReadLine module) (@INC contains: /etc/perl /usr/local/lib/x86_64-linux-gnu/perl/5.32.1 /usr/local/share/perl/5.32.1 /usr/lib/x86_64-linux-gnu/perl5/5.32 /usr/share/perl5 /usr/lib/x86_64-linux-gnu/perl-base /usr/lib/x86_64-linux-gnu/perl/5.32 /usr/share/perl/5.32 /usr/local/lib/site_perl) at /usr/share/perl5/Debconf/FrontEnd/Readline.pm line 7.)
debconf: falling back to frontend: Teletype
Setting up bind9-dnsutils (1:9.16.27-1~deb11u1) ...
Setting up dnsutils (1:9.16.27-1~deb11u1) ...
Processing triggers for libc-bin (2.31-13+deb11u3) ...
Compruebo que el hostname es correcto:
Compruebo que servidor_web
está conectado a las dos redes:
root@servidor_web:/usr/local/apache2# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
30: eth0@if31: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
link/ether 02:42:c0:a8:14:0a brd ff:ff:ff:ff:ff:ff link-netnsid 0
inet 192.168.20.10/24 brd 192.168.20.255 scope global eth0
valid_lft forever preferred_lft forever
32: eth1@if33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
link/ether 02:42:c0:a8:0a:0a brd ff:ff:ff:ff:ff:ff link-netnsid 0
inet 192.168.10.10/24 brd 192.168.10.255 scope global eth1
valid_lft forever preferred_lft forever
Compruebo que hay resolución DNS al nombre de servicio/contenedor servidor_web
→ servidor_mariadb
:
root@servidor_web:/usr/local/apache2# dig servidor_mariadb
; <<>> DiG 9.16.27-Debian <<>> servidor_mariadb
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 38120
;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 0
;; QUESTION SECTION:
;servidor_mariadb. IN A
;; ANSWER SECTION:
servidor_mariadb. 600 IN A 192.168.20.20
;; Query time: 0 msec
;; SERVER: 127.0.0.11#53(127.0.0.11)
;; WHEN: Wed Jun 15 21:08:40 UTC 2022
;; MSG SIZE rcvd: 66
root@servidor_web:/usr/local/apache2# dig db
; <<>> DiG 9.16.27-Debian <<>> db
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 32469
;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 0
;; QUESTION SECTION:
;db. IN A
;; ANSWER SECTION:
db. 600 IN A 192.168.20.20
;; Query time: 0 msec
;; SERVER: 127.0.0.11#53(127.0.0.11)
;; WHEN: Wed Jun 15 21:09:29 UTC 2022
;; MSG SIZE rcvd: 38
Compruebo que hay ping servidor_web
→ servidor_mariadb
:
root@servidor_web:/usr/local/apache2# ping servidor_mariadb
PING servidor_mariadb (192.168.20.20): 56 data bytes
64 bytes from 192.168.20.20: icmp_seq=0 ttl=64 time=0.222 ms
64 bytes from 192.168.20.20: icmp_seq=1 ttl=64 time=0.132 ms
^C--- servidor_mariadb ping statistics ---
2 packets transmitted, 2 packets received, 0% packet loss
round-trip min/avg/max/stddev = 0.132/0.177/0.222/0.045 ms
Ejemplo 1: Despliegue de la aplicación guestbook
Creo el directorio y entro:
atlas@olympus:~/docker$ mkdir guestbook
atlas@olympus:~/docker$ cd guestbook
atlas@olympus:~/docker/guestbook$
Creo el siguiente docker-compose.yml
:
version: '3.1'
services:
app:
container_name: guestbook
image: iesgn/guestbook
restart: always
ports:
- 80:5000
db:
container_name: redis
image: redis
restart: always
Lanzo el escenario:
atlas@olympus:~/docker/guestbook$ docker-compose up -d
Creating network "guestbook_default" with the default driver
Creating redis ... done
Creating guestbook ... done
Listo los contenedores:
atlas@olympus:~/docker/guestbook$ docker-compose ps
Name Command State Ports
-------------------------------------------------------------------------
guestbook python3 app.py Up 0.0.0.0:80->5000/tcp
redis docker-entrypoint.sh redis ... Up 6379/tcp
Pruebo que funciona:
Paro los contenedores:
atlas@olympus:~/docker/guestbook$ docker-compose stop
Stopping guestbook ... done
Stopping redis ... done
Elimino el escenario:
atlas@olympus:~/docker/guestbook$ docker-compose down
Removing guestbook ... done
Removing redis ... done
Removing network guestbook_default
Ejemplo 2: Despliegue de la aplicación temperaturas
Creo el directorio y entro:
atlas@olympus:~/docker$ mkdir temperaturas
atlas@olympus:~/docker$ cd temperaturas/
atlas@olympus:~/docker/temperaturas$
Creo el siguiente docker-compose.yml
:
version: '3.1'
services:
frontend:
container_name: temperaturas-frontend
image: iesgn/temperaturas_frontend
restart: always
ports:
- 80:3000
depends_on:
- backend
backend:
container_name: temperaturas-backend
image: iesgn/temperaturas_backend
restart: always
Lanzo el escenario:
atlas@olympus:~/docker/temperaturas$ docker-compose up -d
Creating network "temperaturas_default" with the default driver
Creating temperaturas-backend ... done
Creating temperaturas-frontend ... done
Listo los contenedores:
atlas@olympus:~/docker/temperaturas$ docker-compose ps
Name Command State Ports
---------------------------------------------------------------------
temperaturas-backend python3 app.py Up 5000/tcp
temperaturas-frontend python3 app.py Up 0.0.0.0:80->3000/tcp
Pruebo que funciona:
Elimino el escenario:
atlas@olympus:~/docker/temperaturas$ docker-compose down
Stopping temperaturas-frontend ... done
Stopping temperaturas-backend ... done
Removing temperaturas-frontend ... done
Removing temperaturas-backend ... done
Removing network temperaturas_default
Ejemplo 3: Despliegue de WordPress + MariaDB
WP con volúmenes
Creo el directorio y entro:
atlas@olympus:~/docker$ mkdir wp_vol
atlas@olympus:~/docker$ cd wp_vol
atlas@olympus:~/docker/wp_vol$
Creo el siguiente docker-compose.yml
:
version: '3.1'
services:
wordpress:
container_name: servidor_wp
image: wordpress
restart: always
environment:
WORDPRESS_DB_HOST: db
WORDPRESS_DB_USER: user_wp
WORDPRESS_DB_PASSWORD: asdasd
WORDPRESS_DB_NAME: bd_wp
ports:
- 80:80
volumes:
- wordpress_data:/var/www/html/wp-content
db:
container_name: servidor_mysql
image: mariadb
restart: always
environment:
MYSQL_DATABASE: bd_wp
MYSQL_USER: user_wp
MYSQL_PASSWORD: asdasd
MYSQL_ROOT_PASSWORD: asdasd
volumes:
- mariadb_data:/var/lib/mysql
volumes:
wordpress_data:
mariadb_data:
Lanzo el escenario:
atlas@olympus:~/docker/wp_vol$ docker-compose up -d
Creating network "wp_vol_default" with the default driver
Creating volume "wp_vol_wordpress_data" with default driver
Creating volume "wp_vol_mariadb_data" with default driver
Creating servidor_wp ... done
Creating servidor_mysql ... done
Listo los contenedores:
atlas@olympus:~/docker/wp_vol$ docker-compose ps
Name Command State Ports
----------------------------------------------------------------------------
servidor_mysql docker-entrypoint.sh mariadbd Up 3306/tcp
servidor_wp docker-entrypoint.sh apach ... Up 0.0.0.0:80->80/tcp
Pruebo que funciona:
Paro los contenedores:
atlas@olympus:~/docker/wp_vol$ docker-compose stop
Stopping servidor_mysql ... done
Stopping servidor_wp ... done
Borro los contenedores:
atlas@olympus:~/docker/wp_vol$ docker-compose rm
Going to remove servidor_mysql, servidor_wp
Are you sure? [yN] y
Removing servidor_mysql ... done
Removing servidor_wp ... done
Elimino el escenario:
atlas@olympus:~/docker/wp_vol$ docker-compose down -v
Removing network wp_vol_default
Removing volume wp_vol_wordpress_data
Removing volume wp_vol_mariadb_data
WP con bind mount
Creo el directorio y entro:
atlas@olympus:~/docker$ mkdir wp_bind_mount
atlas@olympus:~/docker$ cd wp_bind_mount
atlas@olympus:~/docker/wp_bind_mount$
Creo el siguiente docker-compose.yml
:
version: '3.1'
services:
wordpress:
container_name: servidor_wp
image: wordpress
restart: always
environment:
WORDPRESS_DB_HOST: db
WORDPRESS_DB_USER: user_wp
WORDPRESS_DB_PASSWORD: asdasd
WORDPRESS_DB_NAME: bd_wp
ports:
- 80:80
volumes:
- ./wordpress:/var/www/html/wp-content
db:
container_name: servidor_mysql
image: mariadb
restart: always
environment:
MYSQL_DATABASE: bd_wp
MYSQL_USER: user_wp
MYSQL_PASSWORD: asdasd
MYSQL_ROOT_PASSWORD: asdasd
volumes:
- ./mysql:/var/lib/mysql
Lanzo el escenario:
atlas@olympus:~/docker/wp_bind_mount$ docker-compose up -d
Creating network "wp_bind_mount_default" with the default driver
Creating servidor_wp ... done
Creating servidor_mysql ... done
Listo los contenedores:
atlas@olympus:~/docker/wp_bind_mount$ docker-compose ps
Name Command State Ports
----------------------------------------------------------------------------
servidor_mysql docker-entrypoint.sh mariadbd Up 3306/tcp
servidor_wp docker-entrypoint.sh apach ... Up 0.0.0.0:80->80/tcp
Pruebo que funciona:
Elimino el escenario:
atlas@olympus:~/docker/wp_bind_mount$ docker-compose down -v
Stopping servidor_mysql ... done
Stopping servidor_wp ... done
Removing servidor_mysql ... done
Removing servidor_wp ... done
Removing network wp_bind_mount_default
Ejemplo 4: Despliegue de tomcat + nginx
Creo el directorio y entro:
atlas@olympus:~/docker$ mkdir tomcat
atlas@olympus:~/docker$ cd tomcat
atlas@olympus:~/docker/tomcat$
Creo el siguiente docker-compose.yml
:
version: '3.1'
services:
aplicacionjava:
container_name: tomcat
image: tomcat:9.0
restart: always
volumes:
- ./sample.war:/usr/local/tomcat/webapps/sample.war:ro
proxy:
container_name: nginx
image: nginx
ports:
- 80:80
volumes:
- ./default.conf:/etc/nginx/conf.d/default.conf:ro
Obtengo los 2 ficheros que necesito:
atlas@olympus:~/docker/tomcat$ wget https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion5/ejemplo4/default.conf
--2022-06-16 09:27:24-- https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion5/ejemplo4/default.conf
Resolving raw.githubusercontent.com (raw.githubusercontent.com)... 185.199.109.133, 185.199.111.133, 185.199.108.133, ...
Connecting to raw.githubusercontent.com (raw.githubusercontent.com)|185.199.109.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 387 [text/plain]
Saving to: ‘default.conf’
default.conf 100%[=========================================================================================>] 387 --.-KB/s in 0s
2022-06-16 09:27:24 (16.0 MB/s) - ‘default.conf’ saved [387/387]
atlas@olympus:~/docker/tomcat$ wget https://github.com/iesgn/curso_docker_2021/raw/main/ejemplos/sesion5/ejemplo4/sample.war
--2022-06-16 09:28:18-- https://github.com/iesgn/curso_docker_2021/raw/main/ejemplos/sesion5/ejemplo4/sample.war
Resolving github.com (github.com)... 140.82.121.4
Connecting to github.com (github.com)|140.82.121.4|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion5/ejemplo4/sample.war [following]
--2022-06-16 09:28:18-- https://raw.githubusercontent.com/iesgn/curso_docker_2021/main/ejemplos/sesion5/ejemplo4/sample.war
Resolving raw.githubusercontent.com (raw.githubusercontent.com)... 185.199.109.133, 185.199.108.133, 185.199.110.133, ...
Connecting to raw.githubusercontent.com (raw.githubusercontent.com)|185.199.109.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 4606 (4.5K) [application/octet-stream]
Saving to: ‘sample.war’
sample.war 100%[=========================================================================================>] 4.50K --.-KB/s in 0s
2022-06-16 09:28:19 (30.0 MB/s) - ‘sample.war’ saved [4606/4606]
Lanzo el escenario:
atlas@olympus:~/docker/tomcat$ docker-compose up -d
Creating network "tomcat_default" with the default driver
Creating tomcat ... done
Creating nginx ... done
Compruebo que los contenedores están activos:
atlas@olympus:~/docker/tomcat$ docker-compose ps
Name Command State Ports
--------------------------------------------------------------------
nginx /docker-entrypoint.sh ngin ... Up 0.0.0.0:80->80/tcp
tomcat catalina.sh run Up 8080/tcp
Pruebo que funciona:
Elimino el escenario:
atlas@olympus:~/docker/tomcat$ docker-compose down -v
Stopping nginx ... done
Stopping tomcat ... done
Removing nginx ... done
Removing tomcat ... done
Removing network tomcat_default
Ejemplos reales de despliegues usando docker-compose
- Jitsi
- Bitnami
- Guacamole
Ejercicios multicontenedor
Creo el directorio y entro:
atlas@olympus:~/docker$ mkdir prestashop
atlas@olympus:~/docker$ cd prestashop
atlas@olympus:~/docker/prestashop$
Descargo el docker-compose.yml
oficial de bitnami:
curl -sSL https://raw.githubusercontent.com/bitnami/bitnami-docker-prestashop/master/docker-compose.yml > docker-compose.yml
Lo muestro sin modificar:
atlas@olympus:~/docker/prestashop$ cat docker-compose.yml
version: '2'
services:
mariadb:
image: docker.io/bitnami/mariadb:10.6
environment:
# ALLOW_EMPTY_PASSWORD is recommended only for development.
- ALLOW_EMPTY_PASSWORD=yes
- MARIADB_USER=bn_prestashop
- MARIADB_DATABASE=bitnami_prestashop
volumes:
- 'mariadb_data:/bitnami/mariadb'
prestashop:
image: docker.io/bitnami/prestashop:1.7
ports:
- '80:8080'
- '443:8443'
environment:
- PRESTASHOP_HOST=localhost
- PRESTASHOP_DATABASE_HOST=mariadb
- PRESTASHOP_DATABASE_PORT_NUMBER=3306
- PRESTASHOP_DATABASE_USER=bn_prestashop
- PRESTASHOP_DATABASE_NAME=bitnami_prestashop
# ALLOW_EMPTY_PASSWORD is recommended only for development.
- ALLOW_EMPTY_PASSWORD=yes
volumes:
- 'prestashop_data:/bitnami/prestashop'
depends_on:
- mariadb
volumes:
mariadb_data:
driver: local
prestashop_data:
driver: local
Lo muestro modificado:
Lanzo el escenario:
atlas@olympus:~/docker/prestashop$ docker-compose up -d
Creating network "prestashop_default" with the default driver
Creating volume "prestashop_mariadb_data" with local driver
Creating volume "prestashop_prestashop_data" with local driver
Creating prestashop_mariadb_1 ... done
Creating prestashop_prestashop_1 ... done
Muestro los contenedores funcionando:
Muestro la web funcionando:
Creación de imágenes
Creación de imágenes a partir de un contenedor
Lanzo un contenedor:
Hago modificaciones:
root@d42a140c8da0:/# apt update
Get:1 http://security.debian.org/debian-security bullseye-security InRelease [44.1 kB]
Get:2 http://deb.debian.org/debian bullseye InRelease [116 kB]
Get:3 http://deb.debian.org/debian bullseye-updates InRelease [39.4 kB]
Get:4 http://security.debian.org/debian-security bullseye-security/main amd64 Packages [154 kB]
Get:5 http://deb.debian.org/debian bullseye/main amd64 Packages [8182 kB]
Get:6 http://deb.debian.org/debian bullseye-updates/main amd64 Packages [2592 B]
Fetched 8539 kB in 6s (1401 kB/s)
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
1 package can be upgraded. Run 'apt list --upgradable' to see it.
root@d42a140c8da0:/# apt install apache2 -y
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
The following additional packages will be installed:
apache2-bin apache2-data apache2-utils bzip2 ca-certificates file libapr1 libaprutil1 libaprutil1-dbd-sqlite3 libaprutil1-ldap libbrotli1 libcurl4 libexpat1
libgdbm-compat4 libgdbm6 libgpm2 libicu67 libjansson4 libldap-2.4-2 libldap-common liblua5.3-0 libmagic-mgc libmagic1 libncurses6 libncursesw6 libnghttp2-14 libperl5.32
libprocps8 libpsl5 librtmp1 libsasl2-2 libsasl2-modules libsasl2-modules-db libsqlite3-0 libssh2-1 libxml2 mailcap media-types mime-support netbase openssl perl
perl-modules-5.32 procps psmisc publicsuffix ssl-cert xz-utils
Suggested packages:
apache2-doc apache2-suexec-pristine | apache2-suexec-custom www-browser bzip2-doc gdbm-l10n gpm sensible-utils libsasl2-modules-gssapi-mit
| libsasl2-modules-gssapi-heimdal libsasl2-modules-ldap libsasl2-modules-otp libsasl2-modules-sql perl-doc libterm-readline-gnu-perl | libterm-readline-perl-perl make
libtap-harness-archive-perl
The following NEW packages will be installed:
apache2 apache2-bin apache2-data apache2-utils bzip2 ca-certificates file libapr1 libaprutil1 libaprutil1-dbd-sqlite3 libaprutil1-ldap libbrotli1 libcurl4 libexpat1
libgdbm-compat4 libgdbm6 libgpm2 libicu67 libjansson4 libldap-2.4-2 libldap-common liblua5.3-0 libmagic-mgc libmagic1 libncurses6 libncursesw6 libnghttp2-14 libperl5.32
libprocps8 libpsl5 librtmp1 libsasl2-2 libsasl2-modules libsasl2-modules-db libsqlite3-0 libssh2-1 libxml2 mailcap media-types mime-support netbase openssl perl
perl-modules-5.32 procps psmisc publicsuffix ssl-cert xz-utils
0 upgraded, 49 newly installed, 0 to remove and 1 not upgraded.
Need to get 24.6 MB of archives.
After this operation, 111 MB of additional disk space will be used.
Get:1 http://security.debian.org/debian-security bullseye-security/main amd64 libldap-2.4-2 amd64 2.4.57+dfsg-3+deb11u1 [232 kB]
Get:2 http://security.debian.org/debian-security bullseye-security/main amd64 libxml2 amd64 2.9.10+dfsg-6.7+deb11u2 [692 kB]
Get:3 http://deb.debian.org/debian bullseye/main amd64 perl-modules-5.32 all 5.32.1-4+deb11u2 [2823 kB]
Get:4 http://security.debian.org/debian-security bullseye-security/main amd64 openssl amd64 1.1.1n-0+deb11u2 [852 kB]
Get:5 http://security.debian.org/debian-security bullseye-security/main amd64 xz-utils amd64 5.2.5-2.1~deb11u1 [220 kB]
Get:6 http://security.debian.org/debian-security bullseye-security/main amd64 libldap-common all 2.4.57+dfsg-3+deb11u1 [95.8 kB]
Get:7 http://deb.debian.org/debian bullseye/main amd64 libgdbm6 amd64 1.19-2 [64.9 kB]
Setting up libgdbm-compat4:amd64 (1.19-2) ...
Setting up libperl5.32:amd64 (5.32.1-4+deb11u2) ...
Setting up procps (2:3.3.17-5) ...
Setting up libcurl4:amd64 (7.74.0-1.3+deb11u1) ...
Setting up apache2-utils (2.4.53-1~deb11u1) ...
Setting up perl (5.32.1-4+deb11u2) ...
Setting up mailcap (3.69) ...
Setting up mime-support (3.66) ...
Setting up apache2-bin (2.4.53-1~deb11u1) ...
Setting up apache2 (2.4.53-1~deb11u1) ...
Enabling module mpm_event.
Enabling module authz_core.
Enabling module authz_host.
Enabling module authn_core.
Enabling module auth_basic.
Enabling module access_compat.
Enabling module authn_file.
Enabling module authz_user.
Enabling module alias.
Enabling module dir.
Enabling module autoindex.
Enabling module env.
Enabling module mime.
Enabling module negotiation.
Enabling module setenvif.
Enabling module filter.
Enabling module deflate.
Enabling module status.
Enabling module reqtimeout.
Enabling conf charset.
Enabling conf localized-error-pages.
Enabling conf other-vhosts-access-log.
Enabling conf security.
Enabling conf serve-cgi-bin.
Enabling site 000-default.
invoke-rc.d: could not determine current runlevel
invoke-rc.d: policy-rc.d denied execution of start.
Processing triggers for libc-bin (2.31-13+deb11u3) ...
Processing triggers for ca-certificates (20210119) ...
Updating certificates in /etc/ssl/certs...
0 added, 0 removed; done.
Running hooks in /etc/ca-certificates/update.d...
done.
root@d42a140c8da0:/# echo "<h1>Curso Docker</h1>" > /var/www/html/index.html
root@d42a140c8da0:/# exit
exit
Creo una nueva imagen partiendo de los cambios en el contenedor. Esta imagen será el resultado de las capas base + cambios:
atlas@olympus:~$ docker commit contenedor adrianjaramillo/myapache2:v1
sha256:4d7daf41fb1034a6667c2464ac9bcf809d3c6460af908120f755672d66bc6433
Muestro que ya la tengo localmente:
Al lanzar contenedores desde la imagen modificada estamos obligados a indicar el proceso a iniciar, ya que por defecto se ejecuta el de la imagen base y no podemos cambiarlo (por ahora):
atlas@olympus:~$ docker run -d -p 8080:80 \
--name servidor_web \
adrianjaramillo/myapache2:v1 \
bash -c "apache2ctl -D FOREGROUND"
fed43969a4a81ddfe4473097201a271fdd10aa7ee0053caf11193c12e540e321
Muestro que funciona:
Creación de imágenes a partir de un Dockerfile
Creo un directorio donde estará el Dockerfile y lo que se necesite:
atlas@olympus:~/docker$ mkdir build1
atlas@olympus:~/docker$ cd build1
atlas@olympus:~/docker/build1$
El Dockerfile será:
FROM debian:buster-slim
MAINTAINER Adrián Jaramillo Rodríguez "adristudy@gmail.com"
RUN apt-get update && apt-get install -y apache2
COPY index.html /var/www/html/
CMD ["/usr/sbin/apache2ctl", "-D", "FOREGROUND"]
Me bajo un index.html
de prueba:
atlas@olympus:~/docker/build1$ wget https://gist.githubusercontent.com/chrisvfritz/bc010e6ed25b802da7eb/raw/18eaa48addae7e3021f6bcea03b7a6557e3f0132/index.html
--2022-06-16 18:53:29-- https://gist.githubusercontent.com/chrisvfritz/bc010e6ed25b802da7eb/raw/18eaa48addae7e3021f6bcea03b7a6557e3f0132/index.html
Resolving gist.githubusercontent.com (gist.githubusercontent.com)... 185.199.111.133, 185.199.110.133, 185.199.108.133, ...
Connecting to gist.githubusercontent.com (gist.githubusercontent.com)|185.199.111.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 285 [text/plain]
Saving to: ‘index.html’
index.html 100%[=========================================================================================>] 285 --.-KB/s in 0s
2022-06-16 18:53:30 (11.6 MB/s) - ‘index.html’ saved [285/285]
Al final, acabaremos con la siguiente estructura:
atlas@olympus:~/docker/build1$ ls -la
total 16
drwxr-xr-x 2 atlas atlas 4096 Jun 16 18:53 .
drwxr-xr-x 13 atlas atlas 4096 Jun 16 18:37 ..
-rw-r--r-- 1 atlas atlas 216 Jun 16 18:50 Dockerfile
-rw-r--r-- 1 atlas atlas 285 Jun 16 18:53 index.html
Genero la imagen:
atlas@olympus:~/docker/build1$ docker build -t adrianjaramillo/myapache2:v2 .
Sending build context to Docker daemon 3.072kB
Step 1/5 : FROM debian:buster-slim
---> c2303a498941
Step 2/5 : MAINTAINER Adrián Jaramillo Rodríguez "adristudy@gmail.com"
---> Using cache
---> 31ec41690e42
Step 3/5 : RUN apt-get update && apt-get install -y apache2
---> Running in 82497c561473
Get:1 http://deb.debian.org/debian buster InRelease [122 kB]
Get:2 http://security.debian.org/debian-security buster/updates InRelease [65.4 kB]
Get:3 http://deb.debian.org/debian buster-updates InRelease [51.9 kB]
Get:4 http://security.debian.org/debian-security buster/updates/main amd64 Packages [328 kB]
Get:5 http://deb.debian.org/debian buster/main amd64 Packages [7911 kB]
Get:6 http://deb.debian.org/debian buster-updates/main amd64 Packages [8788 B]
Fetched 8487 kB in 1min 9s (123 kB/s)
Reading package lists...
Reading package lists...
Building dependency tree...
Reading state information...
The following additional packages will be installed:
apache2-bin apache2-data apache2-utils bzip2 ca-certificates file
krb5-locales libapr1 libaprutil1 libaprutil1-dbd-sqlite3 libaprutil1-ldap
libbrotli1 libcurl4 libexpat1 libgdbm-compat4 libgdbm6 libgpm2
libgssapi-krb5-2 libicu63 libjansson4 libk5crypto3 libkeyutils1 libkrb5-3
libkrb5support0 libldap-2.4-2 libldap-common liblua5.2-0 libmagic-mgc
libmagic1 libncurses6 libnghttp2-14 libperl5.28 libprocps7 libpsl5 librtmp1
libsasl2-2 libsasl2-modules libsasl2-modules-db libsqlite3-0 libssh2-1
libssl1.1 libxml2 lsb-base mime-support netbase openssl perl
perl-modules-5.28 procps psmisc publicsuffix ssl-cert xz-utils
Suggested packages:
apache2-doc apache2-suexec-pristine | apache2-suexec-custom www-browser
bzip2-doc gdbm-l10n gpm krb5-doc krb5-user sensible-utils
libsasl2-modules-gssapi-mit | libsasl2-modules-gssapi-heimdal
libsasl2-modules-ldap libsasl2-modules-otp libsasl2-modules-sql perl-doc
libterm-readline-gnu-perl | libterm-readline-perl-perl make libb-debug-perl
liblocale-codes-perl openssl-blacklist
The following NEW packages will be installed:
apache2 apache2-bin apache2-data apache2-utils bzip2 ca-certificates file
krb5-locales libapr1 libaprutil1 libaprutil1-dbd-sqlite3 libaprutil1-ldap
libbrotli1 libcurl4 libexpat1 libgdbm-compat4 libgdbm6 libgpm2
libgssapi-krb5-2 libicu63 libjansson4 libk5crypto3 libkeyutils1 libkrb5-3
libkrb5support0 libldap-2.4-2 libldap-common liblua5.2-0 libmagic-mgc
libmagic1 libncurses6 libnghttp2-14 libperl5.28 libprocps7 libpsl5 librtmp1
libsasl2-2 libsasl2-modules libsasl2-modules-db libsqlite3-0 libssh2-1
libssl1.1 libxml2 lsb-base mime-support netbase openssl perl
perl-modules-5.28 procps psmisc publicsuffix ssl-cert xz-utils
0 upgraded, 54 newly installed, 0 to remove and 1 not upgraded.
Need to get 25.6 MB of archives.
After this operation, 112 MB of additional disk space will be used.
Get:1 http://security.debian.org/debian-security buster/updates/main amd64 libssl1.1 amd64 1.1.1n-0+deb10u2 [1551 kB]
Get:2 http://deb.debian.org/debian buster/main amd64 perl-modules-5.28 all 5.28.1-6+deb10u1 [2873 kB]
Get:3 http://deb.debian.org/debian buster/main amd64 libgdbm6 amd64 1.18.1-4 [64.7 kB]
Get:4 http://deb.debian.org/debian buster/main amd64 libgdbm-compat4 amd64 1.18.1-4 [44.1 kB]
Get:5 http://deb.debian.org/debian buster/main amd64 libperl5.28 amd64 5.28.1-6+deb10u1 [3894 kB]
Get:6 http://security.debian.org/debian-security buster/updates/main amd64 libldap-common all 2.4.47+dfsg-3+deb10u7 [90.1 kB]
Get:7 http://security.debian.org/debian-security buster/updates/main amd64 libldap-2.4-2 amd64 2.4.47+dfsg-3+deb10u7 [224 kB]
Get:8 http://security.debian.org/debian-security buster/updates/main amd64 libxml2 amd64 2.9.4+dfsg1-7+deb10u4 [689 kB]
Get:9 http://security.debian.org/debian-security buster/updates/main amd64 xz-utils amd64 5.2.4-1+deb10u1 [183 kB]
Get:10 http://security.debian.org/debian-security buster/updates/main amd64 openssl amd64 1.1.1n-0+deb10u2 [855 kB]
Get:11 http://deb.debian.org/debian buster/main amd64 perl amd64 5.28.1-6+deb10u1 [204 kB]
Get:12 http://deb.debian.org/debian buster/main amd64 libapr1 amd64 1.6.5-1+b1 [102 kB]
Get:13 http://deb.debian.org/debian buster/main amd64 libexpat1 amd64 2.2.6-2+deb10u4 [108 kB]
Get:14 http://deb.debian.org/debian buster/main amd64 libaprutil1 amd64 1.6.1-4 [91.8 kB]
Get:15 http://deb.debian.org/debian buster/main amd64 libsqlite3-0 amd64 3.27.2-3+deb10u1 [641 kB]
Get:16 http://deb.debian.org/debian buster/main amd64 libaprutil1-dbd-sqlite3 amd64 1.6.1-4 [18.7 kB]
Get:17 http://deb.debian.org/debian buster/main amd64 libsasl2-modules-db amd64 2.1.27+dfsg-1+deb10u2 [69.2 kB]
Get:18 http://deb.debian.org/debian buster/main amd64 libsasl2-2 amd64 2.1.27+dfsg-1+deb10u2 [106 kB]
Get:19 http://deb.debian.org/debian buster/main amd64 libaprutil1-ldap amd64 1.6.1-4 [16.8 kB]
Get:20 http://deb.debian.org/debian buster/main amd64 libbrotli1 amd64 1.0.7-2+deb10u1 [269 kB]
Get:21 http://deb.debian.org/debian buster/main amd64 libkeyutils1 amd64 1.6-6 [15.0 kB]
Get:22 http://deb.debian.org/debian buster/main amd64 libkrb5support0 amd64 1.17-3+deb10u3 [65.8 kB]
Get:23 http://deb.debian.org/debian buster/main amd64 libk5crypto3 amd64 1.17-3+deb10u3 [122 kB]
Get:24 http://deb.debian.org/debian buster/main amd64 libkrb5-3 amd64 1.17-3+deb10u3 [370 kB]
Get:25 http://deb.debian.org/debian buster/main amd64 libgssapi-krb5-2 amd64 1.17-3+deb10u3 [158 kB]
Get:26 http://deb.debian.org/debian buster/main amd64 libnghttp2-14 amd64 1.36.0-2+deb10u1 [85.0 kB]
Get:27 http://deb.debian.org/debian buster/main amd64 libpsl5 amd64 0.20.2-2 [53.7 kB]
Get:28 http://deb.debian.org/debian buster/main amd64 librtmp1 amd64 2.4+20151223.gitfa8646d.1-2 [60.5 kB]
Get:29 http://deb.debian.org/debian buster/main amd64 libssh2-1 amd64 1.8.0-2.1 [140 kB]
Get:30 http://deb.debian.org/debian buster/main amd64 libcurl4 amd64 7.64.0-4+deb10u2 [332 kB]
Get:31 http://deb.debian.org/debian buster/main amd64 libjansson4 amd64 2.12-1 [38.0 kB]
Get:32 http://deb.debian.org/debian buster/main amd64 liblua5.2-0 amd64 5.2.4-1.1+b2 [110 kB]
Get:33 http://deb.debian.org/debian buster/main amd64 libicu63 amd64 63.1-6+deb10u3 [8293 kB]
Get:34 http://deb.debian.org/debian buster/main amd64 apache2-bin amd64 2.4.38-3+deb10u7 [1308 kB]
Get:35 http://deb.debian.org/debian buster/main amd64 apache2-data all 2.4.38-3+deb10u7 [165 kB]
Get:36 http://deb.debian.org/debian buster/main amd64 apache2-utils amd64 2.4.38-3+deb10u7 [237 kB]
Get:37 http://deb.debian.org/debian buster/main amd64 lsb-base all 10.2019051400 [28.4 kB]
Get:38 http://deb.debian.org/debian buster/main amd64 mime-support all 3.62 [37.2 kB]
Get:39 http://deb.debian.org/debian buster/main amd64 libncurses6 amd64 6.1+20181013-2+deb10u2 [102 kB]
Get:40 http://deb.debian.org/debian buster/main amd64 libprocps7 amd64 2:3.3.15-2 [61.7 kB]
Get:41 http://deb.debian.org/debian buster/main amd64 procps amd64 2:3.3.15-2 [259 kB]
Get:42 http://deb.debian.org/debian buster/main amd64 apache2 amd64 2.4.38-3+deb10u7 [252 kB]
Get:43 http://deb.debian.org/debian buster/main amd64 netbase all 5.6 [19.4 kB]
Get:44 http://deb.debian.org/debian buster/main amd64 bzip2 amd64 1.0.6-9.2~deb10u1 [48.4 kB]
Get:45 http://deb.debian.org/debian buster/main amd64 libmagic-mgc amd64 1:5.35-4+deb10u2 [242 kB]
Get:46 http://deb.debian.org/debian buster/main amd64 libmagic1 amd64 1:5.35-4+deb10u2 [118 kB]
Get:47 http://deb.debian.org/debian buster/main amd64 file amd64 1:5.35-4+deb10u2 [66.4 kB]
Get:48 http://deb.debian.org/debian buster/main amd64 krb5-locales all 1.17-3+deb10u3 [95.5 kB]
Get:49 http://deb.debian.org/debian buster/main amd64 ca-certificates all 20200601~deb10u2 [166 kB]
Get:50 http://deb.debian.org/debian buster/main amd64 libgpm2 amd64 1.20.7-5 [35.1 kB]
Get:51 http://deb.debian.org/debian buster/main amd64 libsasl2-modules amd64 2.1.27+dfsg-1+deb10u2 [104 kB]
Get:52 http://deb.debian.org/debian buster/main amd64 psmisc amd64 23.2-1+deb10u1 [126 kB]
Get:53 http://deb.debian.org/debian buster/main amd64 publicsuffix all 20211109.1735-0+deb10u1 [125 kB]
Get:54 http://deb.debian.org/debian buster/main amd64 ssl-cert all 1.0.39 [20.8 kB]
debconf: delaying package configuration, since apt-utils is not installed
Fetched 25.6 MB in 1min 54s (224 kB/s)
Selecting previously unselected package perl-modules-5.28.
(Reading database ... 6460 files and directories currently installed.)
Preparing to unpack .../00-perl-modules-5.28_5.28.1-6+deb10u1_all.deb ...
Unpacking perl-modules-5.28 (5.28.1-6+deb10u1) ...
Selecting previously unselected package libgdbm6:amd64.
Preparing to unpack .../01-libgdbm6_1.18.1-4_amd64.deb ...
Unpacking libgdbm6:amd64 (1.18.1-4) ...
Selecting previously unselected package libgdbm-compat4:amd64.
Preparing to unpack .../02-libgdbm-compat4_1.18.1-4_amd64.deb ...
Unpacking libgdbm-compat4:amd64 (1.18.1-4) ...
Selecting previously unselected package libperl5.28:amd64.
Preparing to unpack .../03-libperl5.28_5.28.1-6+deb10u1_amd64.deb ...
Unpacking libperl5.28:amd64 (5.28.1-6+deb10u1) ...
Selecting previously unselected package perl.
Preparing to unpack .../04-perl_5.28.1-6+deb10u1_amd64.deb ...
Unpacking perl (5.28.1-6+deb10u1) ...
Selecting previously unselected package libapr1:amd64.
Preparing to unpack .../05-libapr1_1.6.5-1+b1_amd64.deb ...
Unpacking libapr1:amd64 (1.6.5-1+b1) ...
Selecting previously unselected package libexpat1:amd64.
Preparing to unpack .../06-libexpat1_2.2.6-2+deb10u4_amd64.deb ...
Unpacking libexpat1:amd64 (2.2.6-2+deb10u4) ...
Selecting previously unselected package libssl1.1:amd64.
Preparing to unpack .../07-libssl1.1_1.1.1n-0+deb10u2_amd64.deb ...
Unpacking libssl1.1:amd64 (1.1.1n-0+deb10u2) ...
Selecting previously unselected package libaprutil1:amd64.
Preparing to unpack .../08-libaprutil1_1.6.1-4_amd64.deb ...
Unpacking libaprutil1:amd64 (1.6.1-4) ...
Selecting previously unselected package libsqlite3-0:amd64.
Preparing to unpack .../09-libsqlite3-0_3.27.2-3+deb10u1_amd64.deb ...
Unpacking libsqlite3-0:amd64 (3.27.2-3+deb10u1) ...
Selecting previously unselected package libaprutil1-dbd-sqlite3:amd64.
Preparing to unpack .../10-libaprutil1-dbd-sqlite3_1.6.1-4_amd64.deb ...
Unpacking libaprutil1-dbd-sqlite3:amd64 (1.6.1-4) ...
Selecting previously unselected package libsasl2-modules-db:amd64.
Preparing to unpack .../11-libsasl2-modules-db_2.1.27+dfsg-1+deb10u2_amd64.deb ...
Unpacking libsasl2-modules-db:amd64 (2.1.27+dfsg-1+deb10u2) ...
Selecting previously unselected package libsasl2-2:amd64.
Preparing to unpack .../12-libsasl2-2_2.1.27+dfsg-1+deb10u2_amd64.deb ...
Unpacking libsasl2-2:amd64 (2.1.27+dfsg-1+deb10u2) ...
Selecting previously unselected package libldap-common.
Preparing to unpack .../13-libldap-common_2.4.47+dfsg-3+deb10u7_all.deb ...
Unpacking libldap-common (2.4.47+dfsg-3+deb10u7) ...
Selecting previously unselected package libldap-2.4-2:amd64.
Preparing to unpack .../14-libldap-2.4-2_2.4.47+dfsg-3+deb10u7_amd64.deb ...
Unpacking libldap-2.4-2:amd64 (2.4.47+dfsg-3+deb10u7) ...
Selecting previously unselected package libaprutil1-ldap:amd64.
Preparing to unpack .../15-libaprutil1-ldap_1.6.1-4_amd64.deb ...
Unpacking libaprutil1-ldap:amd64 (1.6.1-4) ...
Selecting previously unselected package libbrotli1:amd64.
Preparing to unpack .../16-libbrotli1_1.0.7-2+deb10u1_amd64.deb ...
Unpacking libbrotli1:amd64 (1.0.7-2+deb10u1) ...
Selecting previously unselected package libkeyutils1:amd64.
Preparing to unpack .../17-libkeyutils1_1.6-6_amd64.deb ...
Unpacking libkeyutils1:amd64 (1.6-6) ...
Selecting previously unselected package libkrb5support0:amd64.
Preparing to unpack .../18-libkrb5support0_1.17-3+deb10u3_amd64.deb ...
Unpacking libkrb5support0:amd64 (1.17-3+deb10u3) ...
Selecting previously unselected package libk5crypto3:amd64.
Preparing to unpack .../19-libk5crypto3_1.17-3+deb10u3_amd64.deb ...
Unpacking libk5crypto3:amd64 (1.17-3+deb10u3) ...
Selecting previously unselected package libkrb5-3:amd64.
Preparing to unpack .../20-libkrb5-3_1.17-3+deb10u3_amd64.deb ...
Unpacking libkrb5-3:amd64 (1.17-3+deb10u3) ...
Selecting previously unselected package libgssapi-krb5-2:amd64.
Preparing to unpack .../21-libgssapi-krb5-2_1.17-3+deb10u3_amd64.deb ...
Unpacking libgssapi-krb5-2:amd64 (1.17-3+deb10u3) ...
Selecting previously unselected package libnghttp2-14:amd64.
Preparing to unpack .../22-libnghttp2-14_1.36.0-2+deb10u1_amd64.deb ...
Unpacking libnghttp2-14:amd64 (1.36.0-2+deb10u1) ...
Selecting previously unselected package libpsl5:amd64.
Preparing to unpack .../23-libpsl5_0.20.2-2_amd64.deb ...
Unpacking libpsl5:amd64 (0.20.2-2) ...
Selecting previously unselected package librtmp1:amd64.
Preparing to unpack .../24-librtmp1_2.4+20151223.gitfa8646d.1-2_amd64.deb ...
Unpacking librtmp1:amd64 (2.4+20151223.gitfa8646d.1-2) ...
Selecting previously unselected package libssh2-1:amd64.
Preparing to unpack .../25-libssh2-1_1.8.0-2.1_amd64.deb ...
Unpacking libssh2-1:amd64 (1.8.0-2.1) ...
Selecting previously unselected package libcurl4:amd64.
Preparing to unpack .../26-libcurl4_7.64.0-4+deb10u2_amd64.deb ...
Unpacking libcurl4:amd64 (7.64.0-4+deb10u2) ...
Selecting previously unselected package libjansson4:amd64.
Preparing to unpack .../27-libjansson4_2.12-1_amd64.deb ...
Unpacking libjansson4:amd64 (2.12-1) ...
Selecting previously unselected package liblua5.2-0:amd64.
Preparing to unpack .../28-liblua5.2-0_5.2.4-1.1+b2_amd64.deb ...
Unpacking liblua5.2-0:amd64 (5.2.4-1.1+b2) ...
Selecting previously unselected package libicu63:amd64.
Preparing to unpack .../29-libicu63_63.1-6+deb10u3_amd64.deb ...
Unpacking libicu63:amd64 (63.1-6+deb10u3) ...
Selecting previously unselected package libxml2:amd64.
Preparing to unpack .../30-libxml2_2.9.4+dfsg1-7+deb10u4_amd64.deb ...
Unpacking libxml2:amd64 (2.9.4+dfsg1-7+deb10u4) ...
Selecting previously unselected package apache2-bin.
Preparing to unpack .../31-apache2-bin_2.4.38-3+deb10u7_amd64.deb ...
Unpacking apache2-bin (2.4.38-3+deb10u7) ...
Selecting previously unselected package apache2-data.
Preparing to unpack .../32-apache2-data_2.4.38-3+deb10u7_all.deb ...
Unpacking apache2-data (2.4.38-3+deb10u7) ...
Selecting previously unselected package apache2-utils.
Preparing to unpack .../33-apache2-utils_2.4.38-3+deb10u7_amd64.deb ...
Unpacking apache2-utils (2.4.38-3+deb10u7) ...
Selecting previously unselected package lsb-base.
Preparing to unpack .../34-lsb-base_10.2019051400_all.deb ...
Unpacking lsb-base (10.2019051400) ...
Selecting previously unselected package mime-support.
Preparing to unpack .../35-mime-support_3.62_all.deb ...
Unpacking mime-support (3.62) ...
Selecting previously unselected package libncurses6:amd64.
Preparing to unpack .../36-libncurses6_6.1+20181013-2+deb10u2_amd64.deb ...
Unpacking libncurses6:amd64 (6.1+20181013-2+deb10u2) ...
Selecting previously unselected package libprocps7:amd64.
Preparing to unpack .../37-libprocps7_2%3a3.3.15-2_amd64.deb ...
Unpacking libprocps7:amd64 (2:3.3.15-2) ...
Selecting previously unselected package procps.
Preparing to unpack .../38-procps_2%3a3.3.15-2_amd64.deb ...
Unpacking procps (2:3.3.15-2) ...
Selecting previously unselected package apache2.
Preparing to unpack .../39-apache2_2.4.38-3+deb10u7_amd64.deb ...
Unpacking apache2 (2.4.38-3+deb10u7) ...
Selecting previously unselected package netbase.
Preparing to unpack .../40-netbase_5.6_all.deb ...
Unpacking netbase (5.6) ...
Selecting previously unselected package bzip2.
Preparing to unpack .../41-bzip2_1.0.6-9.2~deb10u1_amd64.deb ...
Unpacking bzip2 (1.0.6-9.2~deb10u1) ...
Selecting previously unselected package libmagic-mgc.
Preparing to unpack .../42-libmagic-mgc_1%3a5.35-4+deb10u2_amd64.deb ...
Unpacking libmagic-mgc (1:5.35-4+deb10u2) ...
Selecting previously unselected package libmagic1:amd64.
Preparing to unpack .../43-libmagic1_1%3a5.35-4+deb10u2_amd64.deb ...
Unpacking libmagic1:amd64 (1:5.35-4+deb10u2) ...
Selecting previously unselected package file.
Preparing to unpack .../44-file_1%3a5.35-4+deb10u2_amd64.deb ...
Unpacking file (1:5.35-4+deb10u2) ...
Selecting previously unselected package krb5-locales.
Preparing to unpack .../45-krb5-locales_1.17-3+deb10u3_all.deb ...
Unpacking krb5-locales (1.17-3+deb10u3) ...
Selecting previously unselected package xz-utils.
Preparing to unpack .../46-xz-utils_5.2.4-1+deb10u1_amd64.deb ...
Unpacking xz-utils (5.2.4-1+deb10u1) ...
Selecting previously unselected package openssl.
Preparing to unpack .../47-openssl_1.1.1n-0+deb10u2_amd64.deb ...
Unpacking openssl (1.1.1n-0+deb10u2) ...
Selecting previously unselected package ca-certificates.
Preparing to unpack .../48-ca-certificates_20200601~deb10u2_all.deb ...
Unpacking ca-certificates (20200601~deb10u2) ...
Selecting previously unselected package libgpm2:amd64.
Preparing to unpack .../49-libgpm2_1.20.7-5_amd64.deb ...
Unpacking libgpm2:amd64 (1.20.7-5) ...
Selecting previously unselected package libsasl2-modules:amd64.
Preparing to unpack .../50-libsasl2-modules_2.1.27+dfsg-1+deb10u2_amd64.deb ...
Unpacking libsasl2-modules:amd64 (2.1.27+dfsg-1+deb10u2) ...
Selecting previously unselected package psmisc.
Preparing to unpack .../51-psmisc_23.2-1+deb10u1_amd64.deb ...
Unpacking psmisc (23.2-1+deb10u1) ...
Selecting previously unselected package publicsuffix.
Preparing to unpack .../52-publicsuffix_20211109.1735-0+deb10u1_all.deb ...
Unpacking publicsuffix (20211109.1735-0+deb10u1) ...
Selecting previously unselected package ssl-cert.
Preparing to unpack .../53-ssl-cert_1.0.39_all.deb ...
Unpacking ssl-cert (1.0.39) ...
Setting up perl-modules-5.28 (5.28.1-6+deb10u1) ...
Setting up libexpat1:amd64 (2.2.6-2+deb10u4) ...
Setting up lsb-base (10.2019051400) ...
Setting up libkeyutils1:amd64 (1.6-6) ...
Setting up libpsl5:amd64 (0.20.2-2) ...
Setting up libgpm2:amd64 (1.20.7-5) ...
Setting up mime-support (3.62) ...
Setting up libmagic-mgc (1:5.35-4+deb10u2) ...
Setting up psmisc (23.2-1+deb10u1) ...
Setting up libssl1.1:amd64 (1.1.1n-0+deb10u2) ...
debconf: unable to initialize frontend: Dialog
debconf: (TERM is not set, so the dialog frontend is not usable.)
debconf: falling back to frontend: Readline
Setting up libprocps7:amd64 (2:3.3.15-2) ...
Setting up libbrotli1:amd64 (1.0.7-2+deb10u1) ...
Setting up libsqlite3-0:amd64 (3.27.2-3+deb10u1) ...
Setting up libsasl2-modules:amd64 (2.1.27+dfsg-1+deb10u2) ...
Setting up libnghttp2-14:amd64 (1.36.0-2+deb10u1) ...
Setting up libmagic1:amd64 (1:5.35-4+deb10u2) ...
Setting up libapr1:amd64 (1.6.5-1+b1) ...
Setting up krb5-locales (1.17-3+deb10u3) ...
Setting up file (1:5.35-4+deb10u2) ...
Setting up bzip2 (1.0.6-9.2~deb10u1) ...
Setting up libldap-common (2.4.47+dfsg-3+deb10u7) ...
Setting up libicu63:amd64 (63.1-6+deb10u3) ...
Setting up libjansson4:amd64 (2.12-1) ...
Setting up libkrb5support0:amd64 (1.17-3+deb10u3) ...
Setting up libsasl2-modules-db:amd64 (2.1.27+dfsg-1+deb10u2) ...
Setting up librtmp1:amd64 (2.4+20151223.gitfa8646d.1-2) ...
Setting up libncurses6:amd64 (6.1+20181013-2+deb10u2) ...
Setting up xz-utils (5.2.4-1+deb10u1) ...
update-alternatives: using /usr/bin/xz to provide /usr/bin/lzma (lzma) in auto mode
update-alternatives: warning: skip creation of /usr/share/man/man1/lzma.1.gz because associated file /usr/share/man/man1/xz.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/unlzma.1.gz because associated file /usr/share/man/man1/unxz.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzcat.1.gz because associated file /usr/share/man/man1/xzcat.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzmore.1.gz because associated file /usr/share/man/man1/xzmore.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzless.1.gz because associated file /usr/share/man/man1/xzless.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzdiff.1.gz because associated file /usr/share/man/man1/xzdiff.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzcmp.1.gz because associated file /usr/share/man/man1/xzcmp.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzgrep.1.gz because associated file /usr/share/man/man1/xzgrep.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzegrep.1.gz because associated file /usr/share/man/man1/xzegrep.1.gz (of link group lzma) doesn't exist
update-alternatives: warning: skip creation of /usr/share/man/man1/lzfgrep.1.gz because associated file /usr/share/man/man1/xzfgrep.1.gz (of link group lzma) doesn't exist
Setting up libk5crypto3:amd64 (1.17-3+deb10u3) ...
Setting up libsasl2-2:amd64 (2.1.27+dfsg-1+deb10u2) ...
Setting up liblua5.2-0:amd64 (5.2.4-1.1+b2) ...
Setting up procps (2:3.3.15-2) ...
update-alternatives: using /usr/bin/w.procps to provide /usr/bin/w (w) in auto mode
update-alternatives: warning: skip creation of /usr/share/man/man1/w.1.gz because associated file /usr/share/man/man1/w.procps.1.gz (of link group w) doesn't exist
Setting up libssh2-1:amd64 (1.8.0-2.1) ...
Setting up netbase (5.6) ...
Setting up libkrb5-3:amd64 (1.17-3+deb10u3) ...
Setting up apache2-data (2.4.38-3+deb10u7) ...
Setting up openssl (1.1.1n-0+deb10u2) ...
Setting up publicsuffix (20211109.1735-0+deb10u1) ...
Setting up libxml2:amd64 (2.9.4+dfsg1-7+deb10u4) ...
Setting up libgdbm6:amd64 (1.18.1-4) ...
Setting up libaprutil1:amd64 (1.6.1-4) ...
Setting up libldap-2.4-2:amd64 (2.4.47+dfsg-3+deb10u7) ...
Setting up libaprutil1-ldap:amd64 (1.6.1-4) ...
Setting up libaprutil1-dbd-sqlite3:amd64 (1.6.1-4) ...
Setting up ca-certificates (20200601~deb10u2) ...
debconf: unable to initialize frontend: Dialog
debconf: (TERM is not set, so the dialog frontend is not usable.)
debconf: falling back to frontend: Readline
Updating certificates in /etc/ssl/certs...
137 added, 0 removed; done.
Setting up ssl-cert (1.0.39) ...
debconf: unable to initialize frontend: Dialog
debconf: (TERM is not set, so the dialog frontend is not usable.)
debconf: falling back to frontend: Readline
Setting up libgssapi-krb5-2:amd64 (1.17-3+deb10u3) ...
Setting up libgdbm-compat4:amd64 (1.18.1-4) ...
Setting up libperl5.28:amd64 (5.28.1-6+deb10u1) ...
Setting up libcurl4:amd64 (7.64.0-4+deb10u2) ...
Setting up apache2-utils (2.4.38-3+deb10u7) ...
Setting up perl (5.28.1-6+deb10u1) ...
Setting up apache2-bin (2.4.38-3+deb10u7) ...
Setting up apache2 (2.4.38-3+deb10u7) ...
Enabling module mpm_event.
Enabling module authz_core.
Enabling module authz_host.
Enabling module authn_core.
Enabling module auth_basic.
Enabling module access_compat.
Enabling module authn_file.
Enabling module authz_user.
Enabling module alias.
Enabling module dir.
Enabling module autoindex.
Enabling module env.
Enabling module mime.
Enabling module negotiation.
Enabling module setenvif.
Enabling module filter.
Enabling module deflate.
Enabling module status.
Enabling module reqtimeout.
Enabling conf charset.
Enabling conf localized-error-pages.
Enabling conf other-vhosts-access-log.
Enabling conf security.
Enabling conf serve-cgi-bin.
Enabling site 000-default.
invoke-rc.d: could not determine current runlevel
invoke-rc.d: policy-rc.d denied execution of start.
Processing triggers for libc-bin (2.28-10+deb10u1) ...
Processing triggers for ca-certificates (20200601~deb10u2) ...
Updating certificates in /etc/ssl/certs...
0 added, 0 removed; done.
Running hooks in /etc/ca-certificates/update.d...
done.
Removing intermediate container 82497c561473
---> 878ba4d423c6
Step 4/5 : COPY index.html /var/www/html/
---> 4a7b35abef6e
Step 5/5 : CMD ["/usr/sbin/apache2ctl", "-D", "FOREGROUND"]
---> Running in b4ea0360f338
Removing intermediate container b4ea0360f338
---> fa8b78ee9ce4
Successfully built fa8b78ee9ce4
Successfully tagged adrianjaramillo/myapache2:v2
Compruebo que tengo la nueva imagen:
Lanzo un contenedor a partir de esta imagen:
atlas@olympus:~/docker/build1$ docker run -d -p 8080:80 --name servidor_web adrianjaramillo/myapache2:v2
83a16f4cd2bfe74313b38c590697c9d940c3a0d2c3e586e84975748c52e79069
Pruebo que funciona:
Distribución de imágenes
Por fichero
Pasamos la imagen a un .tar
:
El fichero generado ya podríamos pasarlo a cualquier sitio.
Para añadir un .tar
a nuestro repositorio local:
atlas@olympus:~/docker$ docker load -i myapache2.tar
e54f845af4e5: Loading layer [==================================================>] 131.7MB/131.7MB
Loaded image: adrianjaramillo/myapache2:v1
Por Docker Hub
Me autentico:
atlas@olympus:~/docker$ docker login
Login with your Docker ID to push and pull images from Docker Hub. If you don't have a Docker ID, head over to https://hub.docker.com to create one.
Username: adrianjaramillo
Password:
WARNING! Your password will be stored unencrypted in /home/atlas/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-store
Login Succeeded
Subimos a Docker Hub:
atlas@olympus:~/docker$ docker push adrianjaramillo/myapache2:v2
The push refers to repository [docker.io/adrianjaramillo/myapache2]
2f99db70a821: Pushed
928f71c072df: Pushed
10e6bc6fdee2: Mounted from library/debian
v2: digest: sha256:f5e64a6aca0b4642827146857d52f1adf6dcfc6932ba8e844c0ded7a003959d7 size: 948
Cualquier persona se podría bajar nuestra imagen ahora:
atlas@olympus:~/docker$ docker pull adrianjaramillo/myapache2:v2
v2: Pulling from adrianjaramillo/myapache2
c1ad9731b2c7: Already exists
7b785f89fe92: Pull complete
73b5fa52da1c: Pull complete
Digest: sha256:f5e64a6aca0b4642827146857d52f1adf6dcfc6932ba8e844c0ded7a003959d7
Status: Downloaded newer image for adrianjaramillo/myapache2:v2
docker.io/adrianjaramillo/myapache2:v2
Ejemplo 1: Construcción de imágenes con una página estática
Versión 1: Desde una imagen base
Parto de la siguiente estructura:
atlas@olympus:~/docker/ejemplo1build/version1$ ls -la
total 16
drwxr-xr-x 3 atlas atlas 4096 Jun 16 20:44 .
drwxr-xr-x 5 atlas atlas 4096 Jun 16 20:49 ..
-rw-r--r-- 1 atlas atlas 203 Jun 16 20:44 Dockerfile
drwxr-xr-x 4 atlas atlas 4096 Jun 16 20:44 public_html
Muestro el Dockerfile
:
FROM debian
RUN apt-get update && apt-get install -y apache2 && apt-get clean && rm -rf /var/lib/apt/lists/*
ADD public_html /var/www/html/
EXPOSE 80
CMD ["/usr/sbin/apache2ctl", "-D", "FOREGROUND"]
Genero la imagen:
Compruebo que la imagen se ha creado:
atlas@olympus:~/docker/ejemplo1build/version1$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
adrianjaramillo/ejemplo1 v1 78598efe38b7 About a minute ago 235MB
Lanzo un contenedor:
atlas@olympus:~/docker/ejemplo1build/version1$ docker run -d -p 80:80 --name ejemplo1 adrianjaramillo/ejemplo1:v1
54f3831fbfba45202e6cf9019bcf6f8ca68ab557c00f573364ed55c146ec8fe2
Pruebo que funciona:
Versión 2: Desde una imagen con apache2
Muestro el Dockerfile
:
atlas@olympus:~/docker/ejemplo1build/version2$ cat Dockerfile
FROM httpd:2.4
ADD public_html /usr/local/apache2/htdocs/
EXPOSE 80
Genero la imagen:
Lanzo un contenedor:
atlas@olympus:~/docker/ejemplo1build/version2$ docker run -d -p 80:80 --name ejemplo1 adrianjaramillo/ejemplo1:v2
c31ba3ff6a7eb6bfca1388aae222931d503f3159762c2ed1bfe387a4a977c4e6
Pruebo que funciona:
Versión 3: Desde una imagen con nginx
Muestro el Dockerfile
:
atlas@olympus:~/docker/ejemplo1build/version3$ cat Dockerfile
FROM nginx
ADD public_html /usr/share/nginx/html
EXPOSE 80
Genero la imagen:
Lanzo un contenedor:
atlas@olympus:~/docker/ejemplo1build/version3$ docker run -d -p 80:80 --name ejemplo1 adrianjaramillo/ejemplo1:v3
a71cf3e153588cbbc4d7b810e06a7808d2e13203fe11ab107520360abdb92ea1
Pruebo que funciona:
Ejemplo 2: Construcción de imágenes con una aplicación PHP
Versión 1: Desde una imagen base sin PHP
Muestro el Dockerfile
:
FROM debian
RUN apt-get update && apt-get install -y apache2 libapache2-mod-php php && apt-get clean && rm -rf /var/lib/apt/lists/*
ADD app /var/www/html/
RUN rm /var/www/html/index.html
EXPOSE 80
CMD ["/usr/sbin/apache2ctl", "-D", "FOREGROUND"]
Genero la imagen:
Compruebo que la imagen está:
atlas@olympus:~/docker/ejemplo2build/version1$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
adrianjaramillo/ejemplo2 v1 4deacc77ef43 About a minute ago 254MB
Lanzo un contenedor:
atlas@olympus:~/docker/ejemplo2build/version1$ docker run -d -p 80:80 --name ejemplo2 adrianjaramillo/ejemplo2:v1
7629bc3a4ed786025dce58351d80599a7725353d40e0a6c5edb0cb5b7f845ebd
Pruebo que funciona:
Muestro el info.php
:
Versión 2: Desde una imagen con PHP instalado
Muestro el Dockerfile
:
Genero la imagen:
Lanzo un contenedor:
atlas@olympus:~/docker/ejemplo2build/version2$ docker run -d -p 80:80 --name ejemplo2 adrianjaramillo/ejemplo2:v2
863fb6d27a48fbace7bf41a224ebc38db555e3cb9d9635a35506831e2268cacc
Pruebo que funciona:
Muestro el info.php
:
Ejemplo 3: Construcción de imágenes con una aplicación Python
Muestro el Dockerfile
:
FROM debian
RUN apt-get update && apt-get install -y python3-pip && apt-get clean && rm -rf /var/lib/apt/lists/*
COPY app /usr/share/app
WORKDIR /usr/share/app
RUN pip3 install --no-cache-dir -r requirements.txt
EXPOSE 3000
CMD [ "python3", "app.py"]
Genero la imagen:
Compruebo que la imagen está:
atlas@olympus:~/docker/ejemplo3build$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
adrianjaramillo/ejemplo3 v1 5d390f9bcd8e 47 seconds ago 510MB
Lanzo un contenedor:
atlas@olympus:~/docker/ejemplo3build$ docker run -d -p 80:3000 --name ejemplo3 adrianjaramillo/ejemplo3:v1
24db90990b340ce8d14bf76dc5f3f6fbf08608dc31cbb3a14b751f6c843acb42
Pruebo que funciona:
Ciclo de vida de las aplicaciones
Paso 1: Desarrollo de nuestra aplicación
Creo una estructura de página web:
atlas@olympus:~/docker/ciclovida$ mkdir public_html
atlas@olympus:~/docker/ciclovida$ cd public_html
atlas@olympus:~/docker/ciclovida/public_html$ echo "<h1>Prueba</h1>" > index.html
Paso 2: Creación de la imagen Docker
Creo el siguiente Dockerfile
:
Genero la imagen:
atlas@olympus:~/docker/ciclovida$ docker build -t adrianjaramillo/aplicacionweb:v1 .
Sending build context to Docker daemon 3.584kB
Step 1/2 : FROM httpd:2.4
---> acd59370d8fb
Step 2/2 : ADD ./public_html /usr/local/apache2/htdocs/
---> 4415b1fcea4e
Successfully built 4415b1fcea4e
Successfully tagged adrianjaramillo/aplicacionweb:v1
Compruebo que la imagen está:
atlas@olympus:~/docker/ciclovida$ docker image ls
REPOSITORY TAG IMAGE ID CREATED SIZE
adrianjaramillo/aplicacionweb v1 4415b1fcea4e About a minute ago 144MB
Paso 3: Probamos nuestra aplicación en el entorno de desarrollo
Lanzo un contenedor:
atlas@olympus:~/docker/ciclovida$ docker run --name aplweb -d -p 80:80 adrianjaramillo/aplicacionweb:v1
39c8937b5badb9dc5f910498aeaf9380d6aa1b0e326e5ea19c527ff40a499e85
Compruebo que esté activo:
atlas@olympus:~/docker/ciclovida$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
39c8937b5bad adrianjaramillo/aplicacionweb:v1 "httpd-foreground" About a minute ago Up About a minute 0.0.0.0:80->80/tcp aplweb
Pruebo que funciona:
Paso 4: Distribuimos nuestra imagen
Subo a Docker Hub:
atlas@olympus:~/docker/ciclovida$ docker push adrianjaramillo/aplicacionweb:v1
The push refers to repository [docker.io/adrianjaramillo/aplicacionweb]
14d158b7d9db: Pushed
2db1ee0a0f4f: Mounted from library/httpd
857d0bc0663f: Mounted from library/httpd
4a48959ac654: Mounted from library/httpd
4e2b986e3da3: Mounted from library/httpd
ad6562704f37: Mounted from library/wordpress
v1: digest: sha256:414d9c7a3d0b84fc327da8414eb9baa8abf32ce1807dae19d3448c1e0c8f84cb size: 1572
Paso 5: Implantación de la aplicación
Para simular que nuestra máquina es el entorno de producción, borramos nuestra imagen local original...
atlas@olympus:~/docker/ciclovida$ docker rmi adrianjaramillo/aplicacionweb:v1
Untagged: adrianjaramillo/aplicacionweb:v1
Untagged: adrianjaramillo/aplicacionweb@sha256:414d9c7a3d0b84fc327da8414eb9baa8abf32ce1807dae19d3448c1e0c8f84cb
Deleted: sha256:4415b1fcea4ef1b5adf4e912bc4f14670ea4c713b326d16c0ca4452f57852cb0
Deleted: sha256:d2dcb5a1a671e6661428ac9e379493d6e73574bc2befa9c7027ace21ba14ed44
... y nos la volvemos a descargar desde Docker Hub:
atlas@olympus:~/docker/ciclovida$ docker pull adrianjaramillo/aplicacionweb:v1
v1: Pulling from adrianjaramillo/aplicacionweb
42c077c10790: Already exists
77a357ba66a8: Already exists
c56c780a8904: Already exists
ecb885e1c489: Already exists
ba0337d73eed: Already exists
35e5b4af3e12: Pull complete
Digest: sha256:414d9c7a3d0b84fc327da8414eb9baa8abf32ce1807dae19d3448c1e0c8f84cb
Status: Downloaded newer image for adrianjaramillo/aplicacionweb:v1
docker.io/adrianjaramillo/aplicacionweb:v1
Lanzo un contenedor:
tlas@olympus:~/docker/ciclovida$ docker run --name aplweb_prod -d -p 80:80 adrianjaramillo/aplicacionweb:v1
c7bf2af9a3c91426a80e22edd67d72f99a1571512d5ddd7a20f7a7dea3a39134
Pruebo que sigue funcionando:
Paso 6: Modificación de la aplicación
Si modificamos el código de la aplicación tendremos que generar una nueva imagen:
atlas@olympus:~/docker/ciclovida$ cd public_html
atlas@olympus:~/docker/ciclovida/public_html$ echo "<h1>Prueba 2</h1>" > index.html
atlas@olympus:~/docker/ciclovida/public_html$ cd ..
atlas@olympus:~/docker/ciclovida$ docker build -t adrianjaramillo/aplicacionweb:v2 .
Sending build context to Docker daemon 3.584kB
Step 1/2 : FROM httpd:2.4
---> acd59370d8fb
Step 2/2 : ADD ./public_html /usr/local/apache2/htdocs/
---> 44a890a9da01
Successfully built 44a890a9da01
Successfully tagged adrianjaramillo/aplicacionweb:v2
Lanzo un contenedor en el entorno de desarrollo:
atlas@olympus:~/docker/ciclovida$ docker run --name aplweb2 -d -p 80:80 adrianjaramillo/aplicacionweb:v2
22fc8df544b24d536aa745d502ace5215d5e56ef74365e8fb92447db881606af
Pruebo que funciona:
Subo la nueva imagen:
atlas@olympus:~/docker/ciclovida$ docker push adrianjaramillo/aplicacionweb:v2
The push refers to repository [docker.io/adrianjaramillo/aplicacionweb]
aa226b1a6620: Pushed
2db1ee0a0f4f: Layer already exists
857d0bc0663f: Layer already exists
4a48959ac654: Layer already exists
4e2b986e3da3: Layer already exists
ad6562704f37: Layer already exists
v2: digest: sha256:78c66a668b1d4b946edc1a00594480d666fb05ff4ab799d97b5e724afd3ed3ae size: 1572
Elimino la imagen local original:
atlas@olympus:~/docker/ciclovida$ docker rmi adrianjaramillo/aplicacionweb:v2
Untagged: adrianjaramillo/aplicacionweb:v2
Untagged: adrianjaramillo/aplicacionweb@sha256:78c66a668b1d4b946edc1a00594480d666fb05ff4ab799d97b5e724afd3ed3ae
Deleted: sha256:44a890a9da01acbe029eb7ac5a57e5b2c27c114370e0a03e682739f738083f0b
Deleted: sha256:71ba067af316ee14e14780b5ce532be1bb4fc390ae803cc8e29ccff6ae05ebe0
La vuelvo a descargar de Docker Hub:
atlas@olympus:~/docker/ciclovida$ docker pull adrianjaramillo/aplicacionweb:v2
v2: Pulling from adrianjaramillo/aplicacionweb
42c077c10790: Already exists
77a357ba66a8: Already exists
c56c780a8904: Already exists
ecb885e1c489: Already exists
ba0337d73eed: Already exists
0fb57bd0a568: Pull complete
Digest: sha256:78c66a668b1d4b946edc1a00594480d666fb05ff4ab799d97b5e724afd3ed3ae
Status: Downloaded newer image for adrianjaramillo/aplicacionweb:v2
docker.io/adrianjaramillo/aplicacionweb:v2
Lanzo un contenedor:
atlas@olympus:~/docker/ciclovida$ docker run --name aplweb2_prod -d -p 80:80 adrianjaramillo/aplicacionweb:v2
c9be3aaf8cb31898140aeb0967a3063debd44d2587eb01dce0dcb54a8bdb7fca
Pruebo que sigue funcionando:
Ejercicios creación imágenes
Muestro el directorio donde tengo la estructura de mi web y donde tendré el Dockerfile
:
atlas@olympus:~/docker/ejimagenes$ ls -la
total 12
drwxr-xr-x 3 atlas atlas 4096 Jun 17 18:04 .
drwxr-xr-x 18 atlas atlas 4096 Jun 17 17:25 ..
drwxr-xr-x 8 atlas atlas 4096 Jun 17 18:03 public_html
Creo el siguiente Dockerfile
:
Genero la imagen:
Compruebo que la tengo localmente:
atlas@olympus:~/docker/ejimagenes$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
adrianjaramillo/mi_servidor_web v1 c5533b4dd021 2 minutes ago 142MB
Lanzo un contenedor:
atlas@olympus:~/docker/ejimagenes$ docker run -d -p 80:80 --name prueba1 adrianjaramillo/mi_servidor_web:v1
31196fe55dc33d3f818c4c979ba570ff6569c6fde885f1cef433d16bbd2a2f1d
Pruebo que funciona:
Subo la nueva imagen a Docker Hub:
Compruebo que se subió correctamente:
Para simular que nuestra máquina es el entorno de producción, borramos nuestra imagen local original...
atlas@olympus:~/docker/ejimagenes$ docker rmi adrianjaramillo/mi_servidor_web:v1
Untagged: adrianjaramillo/mi_servidor_web:v1
Untagged: adrianjaramillo/mi_servidor_web@sha256:b1ab1fd223167e4a6b5234fa6bde88ae2e677c0cfb19b38abab12a0411ead882
Deleted: sha256:9b1fa17c1533b7f8e6596976bf1e839a9cd15e4b0f58c77008d0a62985e004c4
Deleted: sha256:a9efe2bdee3e0d17ee5316f9eec7489e1c67fa166ed7fb780de3f848ca90380d
Deleted: sha256:07a7bf31da7166779623897641084ec5f05bd7b1095a339ed89b17de8828ccb3
... y nos la volvemos a descargar desde Docker Hub:
Lanzo otro contenedor:
Pruebo que funciona de nuevo:
